IMC/Teddy

IMC/Teddy FT-3096-PFG 96"W x 30"D Floor Trough, 4" Deep, 14 ga Stainless Steel, Fiberglass Grating

SKU: FT-3096-PFG
$7,063.20
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The IMC/Teddy FT-3096-PFG is a 96-inch wide by 30-inch deep floor trough with a 4-inch-deep receptacle. It is constructed from 14 ga Type 304 stainless steel with a brushed satin finish.

  • Includes one 6.5-inch waste outlet, perforated waste basket, and 4-inch OD tailpiece.
  • Includes anchor straps for securing the trough to the floor.
  • Includes gray PFG pultruded fiberglass grating.
  • The FT design includes integral coves and a pitch toward the waste outlet.

Overall Dimensions:

96.0"W x 30.0"D x 12.25"H

Product Weight:

488.0 lb

Stainless steel construction

The trough is made from 14 ga Type 304 stainless steel and has a brushed satin finish.

PFG fiberglass grating

Includes gray pultruded fiberglass grating.

Waste outlet assembly

Includes one 6.5 in waste outlet, a perforated waste basket, and a 4 in OD tailpiece.

Floor anchoring

Includes anchor straps for securing the trough to the floor.

Drainage design

The FT design includes integral coves and a pitch toward the waste outlet.

Related Searches

Best Sellers Cleaning & Janitorial Supplies Commercial Faucets & Plumbing Equipment Floor Drains Floor Drains & Troughs Floor Maintenance IMC/Teddy New Arrivals Plumbing & Water Treatment Sinks & Handwashing Stations
Overall width 96 in
Overall depth 30 in
Overall height 12.25 in
Product weight 488 lb
Receptacle depth 4 in
Trough construction 14 ga Type 304 stainless steel
Finish Brushed satin
Waste outlet 1 x 6.5 in
Tailpiece 4 in OD
Waste basket Perforated
Grating construction Pultruded fiberglass
Grating color Gray
Pan type Non anti-splash

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Documents

PDF Cutsheet PDF Download PDF Seepage flange installation manual PDF Download PDF Floor troughs brochure PDF Download PDF Floor trough installation manual PDF Download

Frequently Asked Questions

The trough is 96 in wide, 30 in deep, and 12.25 in high.
The receptacle is 4 in deep.
The product includes gray PFG pultruded fiberglass grating.
It includes one 6.5 in waste outlet, a perforated waste basket, and a 4 in OD tailpiece.
Yes. Anchor straps are included.
