IMC/Teddy FT-30108 Stainless Steel Floor Trough, 108"W x 30"D, 4" Deep, 2 Waste Outlets
- Construction
- 14/304 stainless steel
- Dimensions
- 108.0"W × 30.0"D × 12.25"H
- Receptacle depth
- 4 in
- Weight
- 192 lb
- Waste outlets
- 2 x 6-1/2 in
- Tailpieces
- 4 in OD
Specifications
Description
IMC/Teddy FT-30108 is a standard floor trough measuring 108 inches wide by 30 inches deep, with a 4-inch-deep receptacle.
It has two 6-1/2-inch waste outlets with perforated waste baskets and 4-inch OD tailpieces. The trough uses 14/304 stainless steel construction, a brushed satin finish, and includes anchor straps.
- Integral coves and a 1/4-inch-per-foot pitch toward the waste outlets
- Recessed flange with a 1-inch ledge for IMC grating
- NSF and Made in USA
Overall Dimensions:
108.0"W x 30.0"D x 12.25"HProduct Weight:
192.0 lbTwo waste outlets
The FT-30108 has two 6-1/2-inch waste outlets.
Included drain components
Perforated waste baskets and 4-inch OD tailpieces are included.
Anchor straps
Anchor straps are included for securing the trough to the floor.
Stainless steel construction
The trough uses 14/304 stainless steel construction.
Drainage design
Integral coves and a 1/4-inch-per-foot pitch direct drainage toward the waste outlets.
Recessed flange
The recessed flange supports floor tile and provides a grout pocket; a 1-inch ledge is integral for IMC grating.
Brushed satin finish
Exposed surfaces have a brushed satin finish.
