IMC/Teddy

IMC/Teddy ASFT18-33-SG-ADA Anti-Splash Stainless Steel Floor Trough with Drain, Subway Grating, 396"W x 18"D x 6" Deep

SKU: ASFT18-33-SG-ADA
$30,144.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

IMC/Teddy ASFT18-33-SG-ADA is an anti-splash stainless steel floor trough for commercial, institutional, and large food preparation facilities. It measures 396 inches wide by 18 inches deep, has a 6-inch pan depth, and includes an SG-ADA subway-style grating and drain.

  • Anti-splash design: Directs splashing waste water toward the inside corners of the trough and away from equipment.
  • Stainless steel construction: Built from 14 ga 304 stainless steel.
  • Drainage design: The trough is integrally pitched toward the waste outlet.
  • SG-ADA grating: Stainless steel subway-style grating with bars spaced 1/2 inch apart and identified as ADA compliant in the product documentation.
  • Installation features: Recessed outer flange supports floor tile and provides a grout pocket.
  • Fabrication: Coved corners, TIG-welded joints, and a brushed-satin exposed finish.

Overall Dimensions:

396.0"W x 18.0"D x 6.0"H

Product Weight:

891.0 lb

Anti-splash pan

Directs splashing waste water to the inside corners of the trough and away from equipment.

14 ga 304 stainless steel construction

The trough is constructed from 14 ga 304 stainless steel.

SG-ADA subway-style grating

Includes stainless steel subway-style grating with bars spaced 1/2 inch apart; the product documentation identifies the SG-ADA bars as ADA compliant.

Integral drainage pitch

The trough is integrally pitched toward the waste outlet.

Coved corners

Horizontal corners are coved as part of the ASFT trough design.

Recessed outer flange

Supports floor tile and provides a grout pocket.

TIG-welded joints

Joints are TIG welded and described as leak-proof in the product documentation.

Brushed-satin finish

Exposed surfaces have a brushed-satin finish.

Related Searches

Best Sellers Cleaning & Janitorial Supplies Commercial Faucets & Plumbing Equipment Floor Drains Floor Drains & Troughs Floor Maintenance IMC/Teddy New Arrivals Plumbing & Water Treatment Sinks & Handwashing Stations
Overall width 396 in
Overall depth 18 in
Pan depth 6 in
Trough construction 14 ga 304 stainless steel
Pan type Anti-splash
Grating type SG-ADA subway-style grating
Grate spacing 1/2 in
Drain Included
Product weight 891 lb

Documents

PDF Cutsheet PDF Download PDF Floor troughs brochure PDF Download PDF Seepage flange installation manual PDF Download PDF Floor trough installation manual PDF Download

Frequently Asked Questions

The authoritative dimensions are 396 in wide by 18 in deep by 6 in high, with a listed 6 in pan depth.
It is constructed from 14 ga 304 stainless steel.
Yes. The exact product specification states that it includes an SG-ADA subway-style grating and a drain.
It directs splashing waste water to the inside corners of the trough and away from equipment.
Yes. The product documentation identifies SG-ADA grating bars as ADA compliant and specifies 1/2-inch spacing.
The listed product weight is 891 lb.
