Icetro America (Middleby)

Icetro America (Middleby) IM-0550-WC Modular Cube Ice Maker, Full-Size Cubes, Water-Cooled, Self-Contained, 547 lb/24 hr, 30"W

SKU: IM-0550-WC
$4,649.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Icetro America IM-0550-WC is a 30-inch modular cube ice maker with a water-cooled, self-contained refrigeration system. It produces up to 547 lb of full-size cube ice per 24 hours at 70°F air and 50°F water, or 483 lb at 90°F air and 70°F water.

  • Construction: 304 stainless steel exterior and ABS antimicrobial interior.
  • Service features: Diagnostic control panel, automatic cleaning cycle, adjustable flush time, and tool-free removal of the water distributor tube and water sump.
  • Electrical: 115 V, 60 Hz, single phase, hardwired connection.

Overall Dimensions:

30.0"W x 24.8"D x 22.6"H

Product Weight:

192.0 lb

Full-size cube ice

Produces full-size or dice cube ice measuring 7/8 in × 7/8 in × 7/8 in.

Water-cooled refrigeration

Uses a water-cooled condenser with self-contained refrigeration.

High production capacity

Produces up to 547 lb per 24 hours at 70°F air and 50°F water, or 483 lb at 90°F air and 70°F water.

Cleaning and maintenance controls

Includes a diagnostic control panel, automatic cleaning cycle, and adjustable flush time.

Service access

The water distributor tube and water sump can be removed without tools; the front door panel is hinged for access.

Antimicrobial interior

The ABS antimicrobial interior is specified to reduce slime and cleaning cost.

Stainless steel exterior

The exterior is constructed from 304 stainless steel.

Ventilated cabinet design

Sides and top are vented for increased ventilation, and the side and back panels use no screws for access.

Related Searches

Best Sellers Commercial Ice Makers Commercial Ice Makers Ice Machines Ice Machines & Handling Ice Makers & Bins Ice Production Equipment Icetro America (Middleby) New Arrivals Refrigeration & Ice Restaurant Equipment
Ice type Full-size / dice cubes
Condenser type Water-cooled
Refrigeration Self-contained refrigeration
Production capacity at 70°F air / 50°F water 547 lb per 24 hr
Production capacity at 90°F air / 70°F water 483 lb per 24 hr
Water usage 20 gal per 100 lb of ice
Energy consumption 4.53 kWh per 100 lb of ice
Electrical 115 V / 60 Hz / 1 ph
Electrical connection Hardwired
Ice cube dimensions 7/8 in × 7/8 in × 7/8 in
Ambient temperature range 50°F to 100°F
Water temperature range 50°F to 90°F
Water pressure range 20 to 80 psi
Refrigerant R-404A
Exterior material 304 stainless steel
Interior material ABS antimicrobial interior

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

3-year parts and labor warranty for the ice maker.

Documents

PDF Cutsheet PDF Download PDF Install service manual PDF Download PDF Exploded view PDF Download PDF Catalog PDF Download PDF User manual PDF Download PDF Middleby financial flyer PDF Download

Frequently Asked Questions

It produces full-size or dice cube ice measuring 7/8 in × 7/8 in × 7/8 in.
It produces up to 547 lb per 24 hours at 70°F air and 50°F water, or 483 lb per 24 hours at 90°F air and 70°F water.
It uses a water-cooled, self-contained refrigeration system.
The unit is rated at 115 V, 60 Hz, single phase, with a hardwired connection.
The unit is 30 in wide, 24.8 in deep, and 22.6 in high.
Yes. It includes an automatic cleaning cycle and adjustable flush time.
The ice maker has 3-year parts and labor coverage. The evaporator has 5-year parts and labor coverage, while the compressor has 5-year parts and 3-year labor coverage.
