Ice-O-Matic  |  Elevation Series™  |  SKU: CIM2047HW

Ice-O-Matic CIM2047HW Elevation Series™ Ice Machines

$10,451.00
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Slope front storage bins Owner's manual Warranty sheet
Related Searches
Ice Machines Ice Makers & Bins

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Ice-O-Matic Elevation Series™ Modular Cube Ice Maker

Model CIM2046W / CIM2047W – Water-Cooled • Half-Cube • 48 in Wide

Produce more than 1,860 lbs of pure, crystal-clear ice every 24 hours while slashing maintenance time and energy costs. Engineered for demanding food-service, hospitality and healthcare operations, the Elevation Series™ sets a new bar for sanitation, efficiency and serviceability.

Why Elevation Series?

  • Industry-leading output: up to 1,860 lbs (844 kg) @ 70 °F air / 50 °F water.
  • Water-cooled, self-contained condenser with top & side dual exhaust for flexible installs.
  • PURE ICE® antimicrobial protection is built-in for the life of the machine—no added cartridges.
  • One-touch sanitize & descale buttons speed up routine cleaning.
  • Dishwasher-safe food-zone parts: snap out, wash, snap back—no tools required.
  • LED status display gives at-a-glance operational insight and service diagnostics.
  • Harvest Assist technology ensures consistent production while cutting energy usage.
  • Durable electroless-nickel plated evaporators backed by up to 7-year warranty*.
  • Corrosion-resistant aluminum chassis & fingerprint-proof plastics look new longer.

Ideal Applications

  • High-volume restaurants & QSRs
  • Hotels, resorts & convention centers
  • Hospitals & healthcare facilities
  • Stadium & arena concession stands
  • Large corporate cafeterias

At-a-Glance Specs

Ice type Half Cube – ⅜ in W × ⅞ in D × ⅞ in H (10 × 22 × 22 mm)
Daily production 1,860 lbs @ 70 °F air / 50 °F water
≈ 1,690 lbs @ 90 °F air / 70 °F water
Dimensions (WxDxH) 48.25 × 24.25 × 26.8 in (1,226 × 616 × 660 mm)
Condenser Water-cooled, self-contained
Water use ≈ 14.8 gal potable / 100 lbs ice
Electrical 208-230 V / 60 Hz – single or three-phase (field-select CIM2046W or CIM2047W)
Refrigerant R404A
Certifications cULus, NSF, CE, Agion® antimicrobial

Recommended Accessories

  • Ice-O-Matic IFQ2-XL water filtration system – reduce scale & extend evaporator warranty to 7 years*
  • SafeIce™ UV Purification System – factory or field installed; eliminates viruses, bacteria & odors
  • 48 in upright bins (B1000-48, B1300-48, B1600-60) or slope-front bins (B110PS) – sold separately
  • 82 oz or 16 oz NSF ice scoops and wall brackets
*Register your machine with an Ice-O-Matic filter installed and replaced every six months to activate the full 7-year parts & labor evaporator warranty (USA & Canada).
Bin required: This listing is for the ice-maker head only. Select a compatible 48 in Ice-O-Matic storage bin to complete your installation.

Features & Specs

Manufacturer

Ice-O-Matic

Brand_name

Elevation Series™

Certifications

NSF, CE, cULus

Height

33.0in

Width

27.0in

Depth

51.0in

Shipping Weight

329.0lbs

Ice Type

half size / half dice cubes

Production per 24 hr

1801 - 1900 lb = 818 - 862 kg

Refrigeration

self-contained refrigeration

Width (side - side)

40 - 49" wide

Condenser Type

water-cooled

Specifications

Elevation Series™ Modular Cube Ice Maker, water cooled, self-contained condenser, dual exhaust top/side discharge, 48"W, approximately 1860 lb production/24 hours at 70°/50° (1690 lb at 90°70°), half size cube, PURE ICE® built in antimicrobial protection, LED status display, one touch sanitize/descaling controls, dishwasher safe food zone components, cULus, NSF, CE
