Ice-O-Matic CIM1447FW Elevation Series™ Ice Machines
Description
Elevation Series™ Modular Cube Ice Maker – Water-Cooled
Approx. 1,560 lb / 24 hr • Full-Size Cube • 48" WideEngineered for high-volume, worry-free ice production, the Ice-O-Matic Elevation Series™ delivers up to 1,560 lbs of crystal-clear full cubes every 24 hours while fitting under a 30" ceiling. Built-in antimicrobial protection, one-touch sanitation and dishwasher-safe components make it the most hygienic high-capacity cuber in its class.
Why you’ll love it
- Pure Ice® Antimicrobial – molded into the food zone to inhibit bacteria for the life of the machine.
- One-Touch Clean – LED-guided sanitize & descale cycle keeps maintenance fool-proof.
- Harvest Assist – consistent ice harvest with lower energy consumption.
- Water-Cooled, Self-Contained Condenser – quiet operation & no hot-air discharge.
- Dishwasher-Safe Food Zone Parts – snap out, wash, snap in; no tools required.
- Space-Saving 26.8" Height – stacks under low ceilings or shelving.
- Dual Exhaust Ports – top or side venting offers unmatched installation flexibility.
- Electroless Nickel-Plated Evaporator – resists corrosion and carries up to a 7-year warranty.
- Durable stainless-steel chassis with fingerprint-resistant polymer front panels.
- cULus, NSF & CE listed for global code compliance.
Technical specs
| Ice production @ 70 °F air / 50 °F water | 1,560 lb (708 kg) / 24 hr |
|---|---|
| Ice production @ 90 °F air / 70 °F water | 1,440 lb (653 kg) / 24 hr |
| Ice style & size | Full Cube – ⅞ × ⅞ × ⅞ in (22 × 22 × 22 mm) |
| Condenser type | Water-cooled, self-contained (R404A refrigerant) |
| Dimensions (W×D×H) | 48.25 × 24.25 × 26.8 in | 1,226 × 616 × 660 mm |
| Electrical (select model) | 208-230 V / 60 Hz – 18.9 A (1-ph) or 12.6 A (3-ph) |
| Water use / 100 lb ice | 14.7 gal potable + 104 gal condenser water |
| Approx. shipping weight | 300 lb (136 kg) |
| Certifications | cULus, NSF, CE |
Recommended ice bins (sold separately)
- B55PS – 510 lb capacity, 30" wide slope-front.
- B700-30 – 680 lb capacity, 48" wide upright.
- B1000-48 – 1,000 lb capacity, 48" wide upright.
- B1300-48 or B1325-60 for operations needing 1,300+ lb storage.
Rock-solid Ice-O-Matic warranty
3-year parts & labor on the entire machine, 5-year parts on the compressor & evaporator, and up to 7-year parts & labor on the evaporator when installed with and maintained on the Ice-O-Matic water-filter program (USA & Canada).
Popular add-ons
- IFQ2-XL water-filtration manifold with IOMQXL cartridges – maximize ice quality and extend warranty.
- SafeIce™ purification system – actively destroys viruses, mold & odors (factory or field install).
- KLSCO 82 oz or KSSCO 16 oz ice scoops with integrated bin holder.
Replaces legacy model ICE1407FW. For professional installation & local code compliance, consult the specification sheet and owner’s manual.
