Ice-O-Matic CIM1446HW Elevation Series™ Ice Machines
$8,833.00
Unit price
/
Unavailable
FREE SHIPPING AVAILABLE!
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Ice-O-Matic CIM1446HW Elevation Series™ Ice Machines is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Ice-O-Matic CIM1446HW Elevation Series™ Ice Machines
$8,833.00
Unit price
/
Unavailable
Description
Elevation Series™ CIM1447W Modular Cube Ice Maker
1,560 lb / 24 hr • Half-Cube • Water-Cooled, Self-ContainedEngineered for high-volume restaurants, hospitality and healthcare, the Ice-O-Matic Elevation Series CIM1447W packs class-leading output into a 26.8"-tall frame while making everyday maintenance as easy as the push of a button.
Key Features
- Up to 1,560 lb of half-cube ice every 24 hours (70 °F air / 50 °F water).
- Water-cooled, self-contained condenser—quiet operation with zero hot-air discharge.
- Patented Pure Ice® antimicrobial technology is molded into food-zone components.
- One-touch Sanitize and Descale cycles plus intuitive LED status display.
- Snap-in, dishwasher-safe food-zone parts remove tool-free for the fastest cleaning in the industry.
- Energy-saving Harvest Assist for lower kWh use and consistent production.
- Space-saving 48.25" W × 24.25" D × 26.8" H cabinet fits perfectly on 48" & 60" Ice-O-Matic bins.
- Rugged stainless-steel exterior and electroless-nickel plated evaporator for long-term reliability.
- cULus, NSF & CE listed for global code compliance.
Model replaces legacy ICE1406HW.
Ice Production & Performance
| Ice type | Half Cube – ⅜" × ⅞" × ⅞" (10 × 22 × 22 mm) |
|---|---|
| Daily production @ 70 °F air / 50 °F water | 1,560 lb (708 kg) |
| Daily production @ 90 °F air / 70 °F water | ≈ 1,397 lb (633 kg) |
| Energy use | 3.9 kWh per 100 lb of ice (90 °F/70 °F) |
| Potable water | 14.7 gal per 100 lb of ice |
| Condenser water | 104 gal per 100 lb of ice |
Technical Specifications
| Model | CIM1447W |
|---|---|
| Condenser type | Water-cooled, self-contained |
| Dimensions (W × D × H) | 48.25" × 24.25" × 26.8" (1,226 × 616 × 660 mm) |
| Electrical | 208-230 V / 60 Hz / 3-Ph • 12.6 MCA • 20 A max breaker |
| Refrigerant | R404A |
| Approx. shipping weight | ≈ 300 lb (136 kg) |
| Certifications | cULus • NSF • CE • Agion Antimicrobial |
Compatible Ice Storage Bins (sold separately)
- B700-30 – 680 lb capacity, no adapter kit required.
- B1000-48 – 1,000 lb capacity, no adapter kit required.
- B110 (Slope Front) – 854 lb capacity, no adapter kit required.
- B1300-48, B1325-60 & B1600-60 – 1,320 - 1,660 lb capacities, adapter kits available.
Fast, Fool-Proof Cleaning
- Remove snap-in baffle, curtain & distribution tube.
- Place components directly in a dishwasher.
- Press Sanitize or Descale; machine automates the rest.
- LEDs count down the cycle and signal when ice production resumes.
Extended Warranty Eligible: Install an Ice-O-Matic IFQ2-XL water-filter manifold and
change IOMQXL cartridges every 6 months to unlock 7-year parts & labor coverage on the evaporator.
Why Elevation Series?
- Up to 20 % more energy-efficient than previous Ice-O-Matic cubers.
- Tool-free food-zone access cuts cleaning time in half.
- BPA-free, recyclable plastics with no exposed foam insulation.
- Optional SafeIce Purification System destroys viruses, mold & odors to keep ice hospital-grade clean.*
*Factory- or field-installed accessory, ordered separately.
Features & Specs
Features & Specs
Manufacturer
Ice-O-Matic
Brand_name
Elevation Series™
Certifications
NSF, CE, cULus
Height
33.0in
Width
27.0in
Depth
51.0in
Shipping Weight
311.0lbs
Production per 24 hr
1501 - 1600 lb = 682 - 726 kg
Ice Type
half size / half dice cubes
Width (side - side)
40 - 49" wide
Refrigeration
self-contained refrigeration
Condenser Type
water-cooled
Specifications
Elevation Series™ Modular Cube Ice Maker, water-cooled, self-contained condenser, dual exhaust top/side air discharge, 48" W, approximately 1560 lb production/24 hours at 70°/50° (1440 lb at 90°/70°), half size cube, PURE ICE® built in antimicrobial protection, LED status display, one touch sanitize/descaling controls, dishwasher safe food zone components, cULus, NSF, CE (Replaces ICE1406HW)
