Ice-O-Matic CIM0530HA Elevation Series™ Ice Machines
Description
Ice-O-Matic Elevation Series™ Modular Half-Cube Ice Maker – 30" Air-Cooled (CIM0530A)
Up to 561 lb of ice every 24 hours • Dual top/side exhaust • Self-contained condenserDesigned for operators who demand performance, cleanliness and installation flexibility, the Elevation Series™ CIM0530A pumps out hundreds of pounds of crystal-clear half-cube ice while reducing your labor, energy and maintenance costs.
Why you’ll love it
- Serious output, compact footprint – 30 in. wide machine produces approximately 561 lb at 70 °F/50 °F and 420 lb at 90 °F/70 °F.
- Exclusive Dual Exhaust™ – hot air discharges from the top or side, letting you tuck the unit into tight spaces without overheating.
- PURE ICE® antimicrobial protection – Agion®-treated internal surfaces inhibit bacteria and slime for the life of the machine.
- One-touch sanitation & descaling – LED interface tells you when to clean; press a button and the machine does the rest.
- Dishwasher-safe Food Zone – BPA-free plastic components snap in/out for a full, tool-free wash.
- Universal Smart Harness™ control board with digital diagnostics speeds installation and service.
- ENERGY STAR® & DOE 2018 compliant – up to 20 % more energy-efficient than prior models.
- Field-friendly – self-contained air-cooled condenser, 6 in. air clearance (top & side), and 115 V plug-and-play power.
Performance you can count on
| Ice type / size | Half-cube (⅜ in × ⅞ in × ⅞ in / 10 × 22 × 22 mm) |
|---|---|
| Daily production (70 °F air / 50 °F water) | ≈ 561 lb / 254 kg |
| Daily production (90 °F air / 70 °F water) | ≈ 420 lb / 190 kg |
| Water usage | 19.9 gal per 100 lb of ice |
| Energy usage | 5.5 kWh per 100 lb of ice |
| Condenser | Air-cooled, self-contained (R404A refrigerant) |
| Electrical | 115 V / 60 Hz / 1-ph, 17.8 A MCA, 30 A max fuse |
| Dimensions (W × D × H) | 30.25 × 24.25 × 21.25 in (768 × 616 × 540 mm) |
| Net / ship weight | ≈ 155 lb (70 kg) |
| Compatible bins (30 in. wide) | B25, B40, B42, B55 & larger (no adapter kit required) |
| Certifications | cULus, NSF, CE, ENERGY STAR®, BPA Free |
Made to stay spotless
- Crevice-free plastic Food Zone lets you wipe down surfaces in seconds.
- All water-distribution components remove without tools and are 100 % dishwasher safe.
- LED status lights show when cleaning is needed, reducing guesswork and service calls.
Built for a greener operation
- Meets or exceeds DOE 2018 energy standards.
- Uses BPA-free, recyclable plastics throughout the Food Zone.
- Optional SafeIce™ UV purification kit (factory or field install) further extends machine life and destroys viruses, odors and mold.
*Ice production ratings are based on half-cube configuration under listed air/water conditions. Actual output will vary with site conditions.
Allow a minimum of 6 in. (152 mm) clearance on both the top and side for proper airflow.
