Hoshizaki Slim-Line 30-Inch Water-Cooled Cubelet Modular Ice Machine

SKU: F-1501MWJ-C
$11,705.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Cut Resistant Gloves Hoshizaki Ice Machines Ice Makers & Bins Kitchen Knives New Arrivals Smallwares

Hoshizaki Slim-Line 30-Inch Water-Cooled Cubelet Modular Ice Machine

Self-Contained Refrigeration, Up to 1,376 lb/24 Hr

Built for high-volume service, this 30-inch modular machine produces compressed cubelet ice with water-cooled performance and stainless steel durability.

  • 30-inch-wide Slim-Line modular ice machine for cubelet ice production.
  • Produces up to 1,376 lb of ice per 24 hours at 70°F/50°F; 1,218 lb AHRI-certified at 90°F/70°F.
  • Water-cooled, self-contained refrigeration helps support consistent output.
  • Advanced CleanCycle24™ and infrared bin control help keep operation cleaner and easier to maintain.
  • Stainless steel exterior and auger with greaseless bearing support long-term durability.
  • Hard-wired 208-230V, single-phase electrical requirements; two units can be mounted side-by-side in 60 inches of floor space.

Overall Dimensions:

30.0"W x 27.38"D x 34.44"H

Product Weight:

330.0 lb

Advanced CleanCycle24™

Automatic flush cycle helps remove sediment for cleaner ice; the flush runs for 2 seconds every hour.

Stainless Steel Exterior

Durable stainless steel construction is built for demanding commercial environments.

Stainless Steel Auger

Greaseless bearing design supports smooth operation and easier serviceability.

Cubelet Ice

Produces compressed cubelet ice, approximately 1/2 inch x 3/4 inch.

High Production Capacity

Produces up to 1,376 lb per 24 hours at 70°F/50°F; AHRI-certified output is 1,218 lb at 90°F/70°F.

Infrared Bin Control

Helps improve reliability and simplifies cleaning.

Water-Cooled, Self-Contained Refrigeration

Built-in refrigeration package is designed for consistent ice production.

Side-by-Side Installation

Two units can be mounted side-by-side in only 60 inches of floor space for increased output.

Type Modular Ice Machine
Style Cubelet
Refrigeration Type Self-Contained
Cooling Type Water-Cooled
Capacity 1,376 lb per 24 Hours
Material Stainless Steel
Finish Stainless Steel
Refrigerant Type R-404A
Voltage 208-230 Volts
Amps 15.4 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type Hard Wired
Breaker Size 20 Amps
BTU 12,800 BTU/hr
Water Connection Required
Drain Connection Required
Water Inlet Size 1/2 Inch FPT
Drain Connection Size 3/4 Inch FPT
Condenser Water Inlet Size 1/2 Inch NPT
Condenser Water Outlet Size 3/8 Inch NPT
Selling Unit Each
Units Per Case 1
Shipping Width 30 Inches
Shipping Depth 28 Inches
Shipping Height 35 Inches
Shipping Weight 330 lb.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Warranty & Protection

3-year parts and labor; 5-year parts on compressor.

Documents

PDF Cutsheet PDF Download PDF Video PDF Download PDF Flyer PDF Download PDF Ice machine brochure PDF Download PDF Parts manual PDF Download PDF Cleaning sheets PDF Download PDF Warranty PDF Download PDF Ice maker calculator PDF Download PDF Owner's manual PDF Download PDF Service manual PDF Download

Frequently Asked Questions

It produces compressed cubelet ice, approximately 1/2 inch x 3/4 inch.
Up to 1,376 lb per 24 hours at 70°F/50°F; 1,218 lb is AHRI-certified at 90°F/70°F.
The unit requires 208-230V, 60 Hz, single-phase power, draws 15.4 amps, and must be hard-wired.
Yes. In addition to the ice maker water and drain connections, the water-cooled model requires separate condenser water inlet and outlet connections.
The cut sheet lists B-250SF, B-700SF, B-900SF, B-1300SS, B-1650SS, B-500SF, B-800SF, B-1150SS, and B-1500SS as compatible bins, and notes that a top kit may be required.
