Hoshizaki

Hoshizaki Steelheart CF36B-L Undercounter Freezer, 36", 6.3 cu. ft., 2 Stainless Steel Drawers, Side-Mounted Self-Contained Refrigeration

SKU: CF36B-L
$8,861.00
Free Shipping
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Steelheart CF36B-L is a one-section, 36.5-inch undercounter freezer chef base with 6.3 cu. ft. of storage, two stainless steel drawers, and side-mounted self-contained refrigeration with the condenser on the left.

  • Stainless steel interior and exterior front, sides, and top.
  • Two stainless steel drawers allow for three 6-inch-deep pans.
  • Four factory-installed 4-inch casters, all with brakes.
  • R290 hydrocarbon refrigerant, a 1/2 HP compressor, and a hot gas condensate evaporator.
  • Solid-state digital controller with temperature alarms and LED display.

Overall Dimensions:

36.5"W x 32.25"D x 26.0"H

Product Weight:

294.0 lb

Left-side condenser

The self-contained refrigeration system is side-mounted with the condenser on the left side.

Two stainless steel drawers

The drawers provide access to the 6.3 cu. ft. freezer interior and allow for three 6-inch-deep pans.

Stainless steel construction

The product has a stainless steel interior and stainless steel exterior front, sides, and top.

Digital temperature control

A solid-state digital controller includes temperature alarms and an LED display.

Hot gas condensate evaporator

Condensate removal uses a hot gas condensate evaporator.

R290 refrigeration

The refrigeration system uses R290 hydrocarbon refrigerant.

Braked casters

Four factory-installed 4-inch casters are included, and all have brakes.

Chef base load capacity

The maximum load capacity is 1,000 lb.

Related Searches

Best Sellers Commercial Freezers Commercial Refrigeration Hoshizaki New Arrivals Refrigeration & Ice Refrigerators & Freezers Restaurant Equipment Undercounter & Worktop Cabinet Equipment Undercounter & Worktop Refrigeration Undercounter Freezers Undercounter Freezers
Configuration One section
Product type Undercounter freezer chef base
Storage capacity 6.3 cu. ft.
Access type Two stainless steel drawers
Width 36.5 in.
Depth 32.25 in.
Height 26.0 in.
Refrigeration Self-contained, side-mounted
Condenser location Left side
Interior construction Stainless steel interior, sides, back, and floor
Exterior construction Stainless steel front, sides, and top
Compressor 1/2 HP
Refrigerant R290 hydrocarbon
Voltage 115 V/60/1-ph
Amperage 4 A
Electrical connection Cord and plug, NEMA 5-15P
Casters Four 4 in. casters, all with brakes; factory installed
Maximum pan depth 6 in.
Pan capacity Three 6 in. deep pans
Maximum load capacity 1,000 lb.
Controller Solid-state digital controller with temperature alarms and LED display
Control setpoint range -12°F to 10°F
Ambient temperature range 45°F to 100°F
Defrost Automatic, time-initiated, heated defrost
Insulation 2 in. CFC-free foamed-in-place polyurethane
Energy consumption 3.37 kWh/day @ ASHRAE

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of ETL Listed
ETL Listed

Warranty & Protection

Seven-year warranty on labor, parts, and compressor.

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The freezer has 6.3 cu. ft. of interior storage capacity.
It uses two stainless steel drawers.
The condenser is located on the left side of the self-contained refrigeration system.
The product specification states that the two drawers allow for three 6-inch-deep pans.
The unit operates at 115 V/60/1-ph and 4 A and uses a cord and plug with a NEMA 5-15P connection.
It uses R290 hydrocarbon refrigerant.
Yes. It includes four factory-installed 4-inch casters, all with brakes.
The product has a seven-year warranty on labor, parts, and the compressor, valid in the United States, Canada, Puerto Rico, and U.S. Territories.
