Hobart BDSRLCD-HTSDOM Warewash Undercounter Dishwashers
Description
Hobart CLeN Steam Blower-Dryer Accessory
Right-to-Left | 480 V / 60 Hz / 3-Phase | DomesticGive every rack a perfectly dry finish as it exits your Hobart CLeN conveyor dishwasher. This steam-heated blower-dryer forces a high-velocity curtain of heated air across the full width of the conveyor, reducing hand-drying labour, speeding turn-around and protecting food-safe results.
Why you’ll love it
- Rapid, even drying – 2 HP industrial blower delivers 200-400 CFM of heated air through a 33 in stainless chamber.
- Steam efficiency – Double-row aluminium fin/copper tube coil uses only 55 lb/hr of steam at 20 psi (max 25 psi).
- Quiet performance – Direct-drive fan and full stainless enclosure keep sound levels low on busy dishlines.
- Seamless integration – Factory-matched to Hobart CLeN series conveyor dishwashers; mounts directly with supplied gasket & hardware.
- Right-to-Left flow – Perfect for dishrooms where ware moves from right-hand load to left-hand unload.
- Automatic operation – Blower starts and stops with the warewasher pumps through the 115 V control circuit.
Compatible CLeN Dishwashers
CL44eN | CLPS66eN | CLCS66eN | CL54eN | CLPS76eN | CLCS76eN | CL64eN | CLPS86eN | CLCS86eN
Technical specifications
| Direction of operation | Right → Left |
|---|---|
| Electrical | 480 V / 60 Hz / 3-phase, 2.6 A, single-point connection (1-1/8 in conduit) |
| Motor | 2 HP, splash-proof, direct-drive Solid-state overload protection (auto-reset) |
| Steam connection | 1 in FPT, 55 lb/hr @ 20 psi (max 25 psi) |
| Condensate return | ¾ in FPT (bucket-type trap furnished) |
| Drain | 1 in FPT in dryer tank |
| Vent/exhaust | 4 in × 16 in vent stack, 400 CFM Canopy hood cannot be used. |
| Chamber length | 33 in (840 mm) |
| Construction | All-stainless steel chamber, tank, legs & enclosure; adjustable stainless feet |
Important: Electrical and plumbing connections must comply with all local codes. Provide a 15 A protected circuit and an independent 4 in × 16 in exhaust duct running 200-400 CFM. Canopy hoods are not permitted above this accessory.
Resources
- Full Hobart CLeN Blower-Dryer Cut Sheet (PDF)
- CAD & Revit files
- Need help choosing? Call Hobart Customer Care at 1-888-4HOBART.
As part of Hobart’s policy of continuous product improvement, specifications are subject to change without notice.
