Description
Hobart CLeN Steam Blower-Dryer Accessory – Right-to-Left
200 – 240 V • 50 Hz • 3-Phase | Standard-Height | Domestic ModelAdd high-speed drying to your Hobart CLeN conveyor dishwasher. This factory-matched steam blower-dryer forces a curtain of heated, high-velocity air across the wareflow, delivering dishes and trays that are dry, cool to handle and ready for immediate service or storage.
Key advantages
- 33 in. stainless steel drying chamber extends dwell time without increasing overall footprint.
- 2 HP direct-drive industrial blower moves 200 – 400 CFM while operating at a low sound level.
- Steam coil heats room air—no electric elements—using only 55 lb/hr of steam at 20 psi.
- Positive forced-air circulation with top-down and redirected up-draft for 360° coverage of ware.
- Smart “blower-on-demand” control runs only when dishwasher pumps are active, saving energy.
- All-stainless construction, splash-proof motor enclosure and wrap-around shroud for long-term durability.
- Ships ready to bolt directly to any compatible Hobart CLeN model—no field fabrication required.
- NSF & cULus listed; meets or exceeds applicable sanitation and safety standards.
Specification highlights
Direction of operation | Right-to-Left |
---|---|
Electrical | 200 – 240 V / 50 Hz / 3-Phase |
Rated amperage | 4.5 A |
Minimum circuit ampacity | 15 A |
Maximum protective device | 15 A |
Blower motor | 2 HP, direct-drive, splash-proof |
Airflow | 200 – 400 CFM |
Steam consumption | 55 lb/hr @ 20 psi (max 25 psi) |
Chamber length | 33 in (838 mm) |
Exhaust connection | 4 in × 16 in vent with locking damper (400 CFM required) |
Plumbing connections | 1 in FPT steam supply • ¾ in FPT condensate return • 1 in FPT drain |
Material | All 300-series stainless steel chamber, tank, legs & adjustable feet |
Compatible warewashers | Hobart CLeN conveyor models (CL44eN, CL54eN, CL64eN, CLCS/CLPS/CLPS, etc.) |
Canopy hoods are not approved for use over this blower-dryer. Provide the dedicated 4 in × 16 in vent connection per installation drawing.
What’s included
- Steam blower-dryer assembly (R-L configuration)
- Mounting hardware & foam gasket
- Bucket-type steam traps
- Installation & operation manual
Upgrade your warewash flow with Hobart’s proven drying technology and keep dishes moving—fast.
