Description
CLeN Series All-Electric Blower-Dryer Accessory
Left-to-Right Operation · 600 V / 60 Hz / 3-PhaseEngineered exclusively for Hobart CLeN conveyor dishwashers, this blower-dryer bolts directly to the clean end of your warewasher and drives a high-velocity curtain of heated air across the conveyor – no manual towel-drying, no waiting, and no bottle-neck at the unload table.
Why you’ll love it
- Rapid, spot-free drying with a positive-pressure air curtain.
- Quiet 2 H.P. direct-drive industrial blower delivers high performance at a low sound level.
- 10 kW Incoloy® electric heater with thermostatic control and independent over-temperature protection.
- 33 in (838 mm) stainless-steel drying chamber – built to the same rugged standard as your Hobart warewasher.
- Baffles below the conveyor recirculate air, minimising heat loss and protecting the operator at the discharge table.
- Single-point, three-phase electrical connection simplifies installation.
- Factory-matched “Dual-Drive” conveyor pawls couple seamlessly to CLeN machines – no field adaptation required.
Performance at a glance
Direction of travel | Left → Right |
---|---|
Electrical spec | 600 V / 60 Hz / 3-Phase |
Rated amps | 12.6 A |
Minimum supply circuit | 20 A |
Maximum protective device | 20 A |
Heating capacity | 10 kW electric (3 × 3.3 kW elements) |
Blower motor | 2 H.P. direct drive |
Airflow | 200 – 400 CFM |
Chamber length | 33 in (838 mm) |
Vent connection | 4 in × 16 in (inside), 400 CFM exhaust |
Installation essentials
- Mounts with nineteen (19) ¼-20 × ⅝ in stainless-steel bolts to the wash chamber – foam gasket supplied.
- Requires a single three-phase connection; control circuit is factory-wired to operate only when the dishwasher pumps are running.
- Provide a 4 in × 16 in vent stack capable of 400 CFM; do not install under a canopy hood.
- Drain connection in dryer tank: 1 in FPT.
Compatible CLeN models
CL44eN · CL54eN · CL64eN · CLP/CLC series (66 in & 76 in) · CLP/CLC series (86 in) – Left-to-Right configuration only.
Specifications subject to change without notice as part of Hobart’s continuous product improvement policy.
