Description
Hobart CLeN All-Electric Blower-Dryer – 380 V, 60 Hz, 3 ph (Right-to-Left)
High-velocity heated-air drying for CLeN conveyor dishwashersFinish every ware cycle bone-dry in a single pass. Designed exclusively for Hobart CLeN Series conveyor dishwashers, this factory-matched blower-dryer forces a curtain of heated air across the full chamber width—speeding turn-around time, saving labor, and keeping your unloading area dry and comfortable.
Key advantages
- Stainless-steel 33 in (838 mm) drying chamber built to the same rugged standard as your CLeN washer.
- 2 H.P. direct-drive industrial blower moves 200–400 CFM with remarkably low sound levels.
- 10 kW Incoloy® electric heaters with thermostatic control and separate over-temperature protection.
- Positive, downward air curtain plus internal baffles recirculate heat for maximum drying and minimal table splash.
- Splash-proof, ventilated motor enclosure for long life in humid ware-wash environments.
- Single-point electrical connection simplifies installation; blower automatically starts and stops with the dishwasher pumps.
- Hobart “Dual-Drive” stainless pawl conveyor section already aligned for seamless mating to your CLeN washer.
At-a-glance specifications
Orientation | Right-to-Left operation (R-L) |
---|---|
Compatible machines | All Hobart CLeN Series conveyor dishwashers* |
Chamber length | 33 in / 838 mm |
Blower motor | 2 H.P. (direct drive) — 3-phase |
Heat capacity | 10 kW total (3 × 3.3 kW Incoloy elements) |
Electrical rating | 380 V / 60 Hz / 3 ph | 17.8 A FLA |
Minimum circuit ampacity | 25 A |
Maximum protective device | 25 A |
Exhaust requirement | 4 in × 16 in duct, 200–400 CFM (no canopy hood) |
Drain connection | 1 in FPT in-tank drain |
Added height above washer | 17 3⁄8 in / 441 mm |
Material & finish | 18-gauge stainless steel, fully welded & bolted |
Installation highlights
- Ships ready to bolt directly to the wash chamber using supplied stainless hardware and foam-tape gasket.
- Controller circuit (115 V) is powered from the dishwasher’s internal transformer—no separate control wiring required.
- Vent stack must remain clear; canopy hoods cannot be used above the dryer section.
- Adjustable stainless feet allow ±¾ in leveling to match the adjacent dishmachine.
*Fits CL44eN, CL54eN, CL64eN, CLPS/CLCS 66eN & 76eN, CLPS/CLCS 86eN conveyor models. Contact us for compatibility questions.
