Hobart BDERLBE-HTSDOM Warewash - Flow Undercounter Dishwashers
Description
CLeN Series All-Electric Blower-Dryer Accessory – 380-415 V, 50 Hz, 3-Ph (Right-to-Left)
Hobart part #: 4271 • Compatible with Hobart CLeN conveyor dishwashersGive your CLeN warewasher a productivity boost with Hobart’s factory-matched blower-dryer module. The stainless-steel unit forces high-velocity, heated air across each rack, sending dinnerware, trays and utensils out of the machine dry, cool to the touch and ready for immediate use or stacking.
Why you’ll love it
- Rapid, hygienic drying – 10 kW of Incoloy® electric heat and a 2 HP blower slash air-dry times.
- Quiet performance – Industrial fan design delivers high velocity with surprisingly low sound levels.
- Energy-smart operation – Blower runs only while the dishwasher pumps are on, reducing wasted power.
- Labor savings – Eliminate hand-towelling and secondary drying racks for faster table turns.
- Built for life – 304 stainless chamber, wrap-around shroud and adjustable stainless legs resist the toughest ware-room environments.
- Simple retrofit – Bolts directly to the CLeN machine through pre-punched holes; no field drilling required.
Technical specifications
| Direction of operation | Right ➜ Left (R-L) |
|---|---|
| Electrical rating | 380-415 V / 50 Hz / 3-phase, 17.8 A |
| Minimum supply circuit | 25 A |
| Maximum protective device | 25 A |
| Heating capacity | 10 kW (3 × 3.3 kW Incoloy® elements) |
| Blower motor | 2 HP, direct-drive, splash-proof enclosure |
| Air volume | 200 – 400 CFM directed vertically downward |
| Chamber length | 33 in (838 mm) |
| Vent connection | 4 in × 16 in (fits inside), 400 CFM exhaust |
| Drain | 1 in FPT in-tank drain |
| Construction | Welded 304 stainless chamber, wrap-around shroud, stainless legs & feet |
| Controller voltage | 115 V supplied by dishwasher transformer |
| Compatible machines | All Hobart CLeN conveyor models (e.g., CL44eN, CLPS66eN, CL64eN, etc.) |
Installation & service highlights
- Single-point electrical connection; 1-1/8 in conduit hole provided (61 in AFF).
- Baffles under the conveyor redirect air upward, minimising heat transfer to discharge table or operators.
- Factory-provided foam gasket ensures a watertight joint between dishwasher and dryer chambers.
- Exhaust canopy hoods cannot be used with this accessory.
- Ventilated room recommended to handle up to 400 CFM exhaust.
Specifications are based on Hobart design data (F40252 – 02/20) and are subject to change without notice.
