Hobart BDERLAB-STDDOM Warewash Undercounter Dishwashers
Description
Hobart CLeN Series All-Electric Blower-Dryer Accessory
Right-to-Left • 200 V / 50 Hz / 3-Phase • Standard HeightUpgrade your Hobart CLeN conveyor dishwasher with rapid, energy-efficient drying power. This factory-matched blower-dryer forces high-velocity heated air across every dish, glass and tray—so you can unload spotless, table-ready ware the moment the rack leaves the machine.
Why you’ll love it
- 33 inch stainless-steel drying chamber resists corrosion and cleans up fast.
- 2 HP industrial blower delivers quiet, high-velocity airflow for consistent results.
- 10 kW Incoloy® electric heaters reach temperature quickly and maintain it efficiently.
- Hobart Dual-Drive conveyor interface—no extra adjustments when switching ware sizes.
- Integrated baffles redirect air to minimise heat at the discharge table and operator station.
- Single-point electrical connection simplifies installation.
Performance built for busy kitchens
- Airflow requirement: 200–400 CFM exhaust through a 4 in × 16 in vent stack.
- Splash-proof, ventilated motor enclosure designed for harsh warewashing environments.
- Automatic blower start/stop is synchronised with the dishwasher pump motors—no wasted energy during idle periods.
- Meets NSF sanitation standards when installed per Hobart specifications.
Technical specifications
| Orientation | Right-to-Left (fits after the final rinse section) |
|---|---|
| Compatible machines | All Hobart CLeN series conveyor dishwashers* |
| Overall chamber length | 33 in (838 mm) |
| Blower motor | 2 HP, direct drive |
| Heating capacity | 10 kW (3 × 3.3 kW Incoloy® elements with thermostat & high-limit) |
| Electrical rating | 200 V / 50 Hz / 3-Ph – 33.0 A (45 A min. circuit, 45 A max protective device) |
| Vent connection | 4 in × 16 in (102 × 406 mm) duct, 400 CFM exhaust |
| Drain connection | 1 in FPT on dryer tank |
| Construction | Fully welded stainless steel chamber, wrap-around enclosure, stainless legs & adjustable feet |
*Requires bolting directly to the wash chamber using provided stainless hardware and foam gasket. Not for use under a canopy hood.
Put an end to towel-drying, speed up turn-around times and elevate your warewashing line with this genuine Hobart dryer accessory—engineered for the performance, reliability and efficiency you expect from the industry leader.
