Hobart BDELRFP-HTSDOM Warewash - Flow Undercounter Dishwashers
Hobart BDELRFP-HTSDOM Warewash - Flow Undercounter Dishwashers is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Hobart BDELRFP-HTSDOM Warewash - Flow Undercounter Dishwashers
Description
Hobart CLeN Series All-Electric Blower Dryer
380 V / 60 Hz / 3-Ph • Left-to-Right (“L-R”) Operation • Part #4271Boost throughput, cut labor, and send every rack out perfectly dry. The Hobart Warewash-Flow blower dryer bolts directly to your CLeN conveyor dishwasher, flooding the ware path with high-velocity heated air for spotless, towel-free results—cycle after cycle.
Key advantages
- 2 HP direct-drive industrial blower delivers quiet, even air flow across the full 33 in. chamber.
- 10 kW Incoloy® electric heat slashes dry times without open-flame hazards.
- Stainless-steel construction and wrap-around enclosure stand up to harsh wash-down environments.
- Baffle system redirects air upward—protecting staff and discharge tables from excess heat.
- Hands-free integration: blower engages automatically with the warewasher pump motors.
- Single-point, three-phase hook-up simplifies electrical installation.
- NSF & cULus listed for food-safe, code-compliant performance.
Technical specifications
| Compatible machines | Hobart CLeN conveyor series (CL44eN, CL54eN, CL64eN, CLPS/CLCS 66-86eN) |
|---|---|
| Direction of travel | Left ➜ Right (factory “L-R”) |
| Voltage / phase / hertz | 380 V / 3-phase / 60 Hz |
| Full-load amps | 17.8 A |
| Min. circuit ampacity | 25 A |
| Max. protective device | 25 A |
| Heating capacity | 10 kW (3 × 3.3 kW elements) |
| Blower motor | 2 HP, splash-proof, ventilated |
| Exhaust requirement | 400 CFM, 4 in. × 16 in. vent stack |
| Chamber length | 33 in. (838 mm) |
| Height above machine | ≈ 17 3⁄8 in. (441 mm) |
| Material | All stainless steel with adjustable feet |
Need a different voltage or a right-to-left configuration? Ask us about factory-built alternatives.
Built for the long haul
Hobart has led commercial warewashing for more than 100 years. Every accessory is engineered, built and tested in the USA, then supported nationwide by Hobart’s legendary service network.
