Hobart  |  Warewash  |  SKU: BDELRET-STDDOM

Hobart BDELRET-STDDOM Warewash Undercounter Dishwashers

$15,499.01
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hobart All-Electric Blower-Dryer – 600 V L-to-R

Factory-matched drying accessory for CLeN Series conveyor dishwashers

Move racks straight from the conveyor to storage—no wiping, no waiting. Hobart’s blower-dryer delivers a curtain of heated, high-velocity air that turns freshly washed wares into immediately usable inventory, keeping your dishroom efficient and your staff productive.

Top benefits at a glance

  • 33 in. stainless-steel chamber installs seamlessly on any Hobart CLeN model
  • 10 kW Incoloy® electric heater controlled by thermostat & independent high-limit
  • 2 HP direct-drive industrial blower moves up to 400 CFM while operating quietly
  • Full-width air orifice & internal baffles ensure thorough, even drying
  • “Dual Drive” stainless conveyor pawls synchronize perfectly with the warewasher
  • Runs only when wash pumps are on, reducing energy use and noise between cycles

Technical specifications

Series compatibility Hobart CLeN conveyor dishwashers
Direction of operation Left → Right
Electrical requirement 600 V / 60 Hz / 3-phase (single-point connection)
Rated amps 12.6 A
Minimum circuit ampacity 20 A
Heat output 10 kW (3 × 3.3 kW elements)
Blower motor 2 HP, splash-proof, ventilated
Vent connection 4 in. × 16 in. stack, 200–400 CFM exhaust
Drain 1 in. FPT in dryer tank
Electrical knockout 1 ⅛ in. conduit, 61 in. above floor
Chamber height increase ≈ 17 ⅜ in. above warewasher

Why add a Hobart blower-dryer?

  • Eliminates hand-drying labor and linen costs
  • Prevents moisture that can harbor bacteria or spot glassware
  • Keeps hot air away from operators—baffles redirect flow back into the chamber
  • Supports HACCP programs with consistently dry, sanitary wares
Installation notice: This unit is engineered exclusively for Hobart CLeN dishwashers and must be connected to a dedicated 600 V, 3-phase circuit and 4 × 16 in. exhaust duct. Canopy hoods cannot be used with the blower-dryer. All electrical and plumbing work must comply with local codes.

Looking for a different voltage or Right-to-Left flow? Contact us for alternate configurations and lead times.

Features & Specs

Manufacturer

Hobart

Brand_name

Warewash

Specifications

Blower Dryer, Electric, L - R, 600v/60/3-ph, Standard Height, Domestic
