Hobart  |  Warewash  |  SKU: BDELRET-STDCAN

Hobart BDELRET-STDCAN Warewash Undercounter Dishwashers

$15,499.01
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Terms & conditions
Related Searches
Bar Equipment Dishwashers Undercounter Dishwashers

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hobart CLeN Series Electric Blower-Dryer Accessory – 600 V, Left-to-Right

High-velocity drying module for Hobart CLeN conveyor dishwashers

Eliminate hand-towelling and speed up turn-around times. Hobart’s all-electric blower-dryer forces heated air across every dish, tray and glass as they exit your CLeN warewasher—so items reach the dishroom table bone-dry and immediately ready for service or storage.

Key performance advantages

  • Stainless steel 33 in. chamber seamlessly bolts to CLeN machines.
  • 2 HP direct-drive industrial blower moves 200–400 CFM of air while running remarkably quiet.
  • 10 kW Incoloy® electric heaters deliver consistent, energy-efficient heat.
  • Positive forced-air curtain spans full conveyor width for even drying.
  • Internal baffles redirect airflow upward—keeping heat off the unload table and operator.
  • Hobart “Dual-Drive” conveyor pawls ensure jam-free ware movement through the drying zone.
  • All-stainless construction, welded and bolted, stands up to years of chemical and moisture exposure.

Technical specifications

Direction of operation Left-to-Right
Electrical 600 V / 60 Hz / 3-phase
Rated current 12.6 A
Minimum circuit ampacity 20 A
Maximum protective device 20 A
Blower motor 2 HP, splash-proof, ventilated
Heating capacity 10 kW (3 × 3.3 kW Incoloy® elements)
Chamber height above machine ≈ 17 ⅜ in.
Vent connection 4 in. × 16 in. stack (400 CFM exhaust)
Drain connection 1 in. FPT in dryer tank
Certifications cULus • NSF

Compatible CLeN models

Designed for Hobart CLeN conveyor dishwashers, including CL44eN, CL54eN, CL64eN and multi-tank CLPS/CLCS variants. Orientation must match machine flow.

Installation & utilities

  • Ships as a bolt-on module; supplied stainless hardware and foam gasket ensure a leak-free joint.
  • Single-point 3-phase electric connection—control circuit is powered through the dishwasher.
  • 4 in. × 16 in. vent stack required; canopy hoods cannot be used with this dryer.
  • Controller interlocks with dishwasher pumps; blower runs only when the machine is washing.
Important: This is an accessory, not a stand-alone dryer. A Hobart CLeN conveyor dishmachine is required for operation.

Continuous product improvement is a Hobart policy; specifications may change without notice.

Features & Specs

Manufacturer

Hobart

Brand_name

Warewash

Specifications

Blower Dryer, Electric, L - R, 600v/60/3-ph, Standard Height, Domestic
