Hobart BDELRBE-STDDOM Warewash Undercounter Dishwashers
Hobart BDELRBE-STDDOM Warewash Undercounter Dishwashers is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Hobart CLeN Series All-Electric Blower-Dryer Accessory
Left-to-Right • 380–415 V / 50 Hz / 3-Phase • Standard HeightSlash labour, speed up turn-around and send perfectly dry tableware straight from your CLeN conveyor dishwasher to service. Hobart’s stainless-steel blower-dryer floods every rack with high-velocity, thermostatically-heated air—no towels, no waiting, no water spots.
Key Performance Features
- 33 inch stainless drying chamber integrates seamlessly with Hobart CLeN models.
- 2 HP industrial direct-drive blower delivers powerful airflow while maintaining low sound levels.
- 10 kW Incoloy® electric heaters with thermostat and independent high-limit protection.
- Positive forced circulation: air is driven vertically down and recaptured by internal baffles for maximum drying efficiency.
- Single-point 3-phase electrical hookup simplifies installation and service.
- Wrap-around stainless housing protects heater & motor from warewasher moisture.
- Hobart “Dual Drive” stainless conveyor pawls transfer ware smoothly from rinse to dry section.
- Adjustable stainless legs match standard CLeN machine height for a perfect, level install.
- NSF & UL listed for rigorous commercial applications.
Why Add a Blower-Dryer?
- Eliminate manual towel drying and cross-contamination.
- Accelerate tray-make and dish-return cycles to keep peak-service traffic flowing.
- Lower operating costs by freeing staff for higher-value tasks.
- Deliver spotless, table-ready plates that impress guests and health inspectors alike.
Technical Specifications
Direction of Operation | Left to Right |
---|---|
Electrical | 380–415 V / 50 Hz / 3-phase, 17.8 A rated • 25 A min. supply • 25 A max. OCPD |
Heating Elements | 3 × 3.3 kW Incoloy® (10 kW total) |
Blower Motor | 2 HP, splash-proof, ventilated, direct drive |
Vent Connection | 4" × 16" stack • 200–400 CFM exhaust |
Chamber Length | 33" (838 mm) |
Height Above Machine | ≈ 17 ⅜" (442 mm) |
Tank Drain | 1" FPT |
Compatible Dishwashers | All Hobart CLeN conveyor models (CL44eN, CL54eN, CL64eN, CLP/CLC Series, etc.) |
Construction | All-welded stainless chamber, wrap-around enclosure, stainless legs & feet |
Installation Notes
- Mounts directly to CLeN dishmachine using supplied stainless hardware & foam gasket.
- Single 1 ⅛" electrical knockout located 61" above finished floor.
- Canopy hoods cannot be used; connect to dedicated vent stack.
Need an alternate voltage or right-to-left flow? Get in touch for customised configurations.
