Hobart BDELRAX-STDDOM Warewash Undercounter Dishwashers
Hobart BDELRAX-STDDOM Warewash Undercounter Dishwashers is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Hobart CLeN Series All-Electric Blower-Dryer
Left-to-Right • 208 V / 60 Hz / 3-PhBolt this factory-engineered blower-dryer to your Hobart CLeN conveyor dishwasher and send every rack out bone-dry, spotless and ready for service—no hand-toweling, no bottlenecks and no added labor.
Why You’ll Love It
- Stainless steel 33 in drying chamber built for relentless commercial use.
- 2 HP direct-drive blower moves 200–400 CFM of air while keeping noise low.
- 10 kW Incoloy® electric heaters with thermostat & independent high-limit safeguard.
- Positive, forced-air circulation attacks water on dishes, flatware and trays for faster table-readiness.
- Runs only while the dishwasher is operating—no wasted energy.
- Quick bolt-on installation; Hobart “Dual Drive” conveyor pawls mate seamlessly to CLeN machines.
- NSF & cULus listed for sanitation and safety compliance.
Technical Specifications
Orientation | Left-to-Right (Loader ➜ Unloader) |
---|---|
Electrical | 208 V / 60 Hz / 3-Phase, 34.2 A Min. Circuit Ampacity 45 A • Max. OCPD 45 A |
Heating Elements | 3 × 3.3 kW (Incoloy) — Total 10 kW |
Blower Motor | 2 HP, splash-proof, ventilated |
Airflow | 200 – 400 CFM forced, heated air |
Chamber Length | 33 in (838 mm) |
Vent Connection | 4 × 16 in (102 × 406 mm) – 400 CFM exhaust |
Drain Connection | 1 in FPT in dryer tank |
Construction | All stainless steel chamber, tank & wrap-around enclosure; stainless adjustable feet |
Compatibility | Hobart CLeN conveyor dishwashers (CL44eN, CL54eN, CL64eN, CLPS/CS models & more) |
Certifications | NSF, cULus |
Installation Notes
- Single-point electrical connection—1 ⅛ in conduit knockout, 61 in AFF.
- Provide dedicated 400 CFM exhaust; canopy hoods cannot be used with this accessory.
- Use supplied foam-tape gasket and stainless hardware to bolt dryer to dishwasher tank.
- All electrical and plumbing work must comply with NEC and local codes.
Dishwasher, tables and vent hood shown in marketing images are sold separately.
