Hobart AMTL-2 Warewash Dishwashers
Description
Hobart AMTL Two-Level High-Temp Door-Type Dishwasher
Model AMTL | 80 racks per hour | Smart Touchscreen ControlsGet twice the warewashing power in the footprint of a single machine. The Hobart AMTL packs two completely independent wash chambers, each with its own pumped-rinse system, into a pillar-less door-type design that speeds through up to 80 racks per hour while using just 0.62 gal of water per rack. With high-temperature sanitizing, Sense-A-Temp™ 60 °F-rise booster and WiFi-enabled smart controls, the AMTL delivers Hobart performance, cloud-based insights and industry-leading efficiency in one sleek stainless-steel package.
Why You’ll Love It
- Two independent chambers – wash pots above and plates below simultaneously.
- Separate pumped-rinse systems in both levels ensure consistent final-rinse pressure and temperature.
- Blazing throughput – up to 80 racks per hour with selectable 1, 2, 4 or 6-minute cycles; lower chamber includes 3 & 6-minute utensil cycles.
- Water miser – just 0.62 gal / rack in each chamber (max 49.6 gal hr).
- Smart touchscreen + WiFi – on-board diagnostics, cycle data and Hobart Smart Connect app.
- Sense-A-Temp™ booster – built-in 12.2 kW heater guarantees 180 °F final-rinse for NSF sanitization.
- AutoFill & AutoClean with door-actuated start for hands-free operation.
- 5-sided insulated hood & lower insulated door retain heat, cut energy use and quiet operation.
- Two-stage filtration with slanted stainless scrap screen & basket keeps wash water cleaner longer.
- Straight-through installation, single-point electric connection and pumped drain simplify placement.
Performance at a Glance
| Racks / Hour (max) | 80 |
|---|---|
| Water per Rack | 0.62 gal (upper) / 0.62 gal (lower) |
| Wash Tank Capacity | 7.9 gal |
| Door Opening | 17" upper | 8 ⅞" lower (accepts 7" plates) |
| Cycle Times | 1, 2, 4, 6 min (upper & lower); utensil 3 & 6 min (lower) |
| Booster Heater | 12.2 kW electric (60 °F rise) |
| Wash Pump Motor | 2.0 HP self-draining with stainless impeller |
Utilities & Installation
- 208–240 V / 60 Hz / 3-phase standard; field convertible to single-phase.
- Single-point electrical connection (field convertible to dual-point).
- 120 °F incoming potable water, 15–65 PSI recommended.
- Pumped drain with 6.5' hose; max drain height 40".
- Exhaust requirement: 450 CFM (when vent hood is used).
- Shipping weight: 555 lb • Crated size: 35.4" L × 39.4" W × 70.9" H.
Factory start-up is included at no charge for installations within 100 miles of a Hobart Service office (accessible by public roadway; standard business hours). Sites beyond this radius will be quoted by Hobart Service.
Built to Last
- Stainless steel drawn tank, tank shelf, chambers, trim panels, frame & feet.
- Spring-counterbalanced doors with thermoplastic rollers for effortless lifting.
- Interchangeable stainless wash & rinse arms (upper) and snap-in arms (lower) for quick cleaning.
- Pillar-less opening simplifies rack loading and cleaning access.
- Temperature & delime lockouts safeguard sanitation and extend machine life.
Certifications & Warranty
- cULus & NSF listed for electrical safety and food-service sanitation.
- Energy-saving design meets or exceeds current sustainability guidelines.
- 1-year parts & labor warranty backed by the Hobart nationwide service network.
