Hobart  |  Warewash  |  SKU: AM16VL-ADV-2

Hobart AM16VL-ADV-2 Warewash Undercounter Dishwashers

$27,468.98
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hobart AM16VL-ADV Advansys™ Ventless High-Temp Dishwasher

40 Racks/Hr • Automatic Soil Removal • Energy Recovery

The AM16VL-ADV turns every dishroom into a hood-free, high-performance wash centre. Ventless energy recovery, Wi-Fi connected controls and a best-in-class 0.67 gal per rack final rinse make this door-type machine the smart way to slash utility costs while delivering spotless, high-temperature sanitation.

Why You’ll Love It

  • Ventless operation—built-in condenser & Drain Water Energy Recovery (DWER) eliminate the need for a dedicated exhaust hood.
  • High-temperature sanitizing rinse (180 °F) powered by a 7.1 kW Sense-A-Temp™ booster heater.
  • Automatic Soil Removal (ASR) skims food debris into a removable basket, extending wash water life and cutting chemical use.
  • Ultra-low water consumption: just 0.67 gal per rack—up to 50 % less than traditional door-style machines.
  • Smart touchscreen with Wi-Fi and Hobart SmartConnect app for temperature logs, usage analytics and real-time error alerts.
  • Field convertible electrical: 208-240 V, 60 Hz, 3-ph standard—switchable to single-phase on site.
  • Four NSF-approved cycles (1, 2, 4 or 6 min) provide a true Pot & Pan setting for baked-on soils.
  • Flexible straight-through or corner installation with a pillar-less 17" opening for sheet pans and trays.
  • X-shaped anti-clog stainless wash arms plus interchangeable stainless rinse arms give full-coverage cleaning.
  • Complete Delime™ system with on-screen reminder, automatic chemical dosing and Booster Guard™.
  • Pumped drain with built-in air gap and factory drain-water tempering for code compliance.
  • Rugged all-stainless tank, hood, frame and feet—backed by a 1-year parts & labour warranty and FREE factory start-up*.

Performance Built for Volume

  • 40 racks per hour = up to 1,000 dishes or 1,800 glasses.
  • Self-draining 2 HP wash pump with stainless impeller.
  • Door-actuated start, AutoFill and AutoClean speed turn-around between loads.
  • Five-sided insulated hood keeps heat in the machine and out of the dishroom.

Certifications & Sustainability

  • ENERGY STAR® Qualified
  • cULus & NSF Listed
  • Meets 2023 DOE commercial dishwasher efficiency standards

Key Specifications

Capacity / Performance
Racks per hour 40
Final rinse water use 0.67 gal / rack (26.8 gal / hr)
Cycle times 1, 2, 4 or 6 minutes
Wash tank capacity 10.5 gal
Door opening height 17 in
Utilities
Electrical (standard) 208-240 V / 60 Hz / 3-ph, single-point connection
Field convertible Single-phase
Rated amperage (3-ph) 26.9 A
Booster heater 7.1 kW Sense-A-Temp™ (70 °F rise)
Tank heat 5.4 kW electric
Water inlet 55 °F min, 3⁄4" GHT hose (supplied)
Drain connection 1-1/2" pumped with tempering kit
Dimensions & Weight
Footprint (W × D × H) 25-3/16" × 24-7/16" × 78-1/2"
Shipping weight ≈ 377 lb

*Factory start-up is free for installations within 100 miles of a Hobart Service Office during normal business hours. Travel beyond 100 miles is available at quoted rates.

Important: Maintain incoming water hardness ≤ 3 grains and a room temperature ≥ 65 °F for optimal performance. Installation must comply with all local electrical and plumbing codes.

Features & Specs

Manufacturer

Hobart

Brand_name

Warewash

Certifications

NSF, cULus, ENERGY STAR

Racks

single

Energy Efficiency

ENERGY STAR®

Tank Heat

electric

Construction

stainless steel

Temperature

high temp with booster

Design

universal (straight-thru/corner)

Rack Capacity

approximately (40) racks/hour

Specifications

Ventless Dishwashing Machine, door type, energy recovery, automatic soil removal (ASR), drain water energy recovery (DWER), high temp sanitizing, 208-240/60/3 (field convertible to single phase), internal condensing system, 40 racks/hour, straight-thru or corner installation, user-friendly smart touchscreen controls, Wi-Fi connectivity with SmartConnect app, Complete Delime™ with Delime Notification, Auto Dispensing, and Booster Guard™, Sense-A-Temp™ booster, electric tank heat, X-shaped wash arms, scrap screen and basket, door actuated start, door lock, stainless steel tank, tank shelf, chamber, trim panels, frame & feet, pumped drain air gap, drain water tempering, cULus, NSF, ENERGY STAR®. Factory Startup - Free for installations within 100 miles of a Hobart Service Office during normal business hours with appropriate notice; installation beyond 100 miles will be quoted by Service.
