Hatco UGAL-18D3 Ultra-Glo® Heat Lamps
Description
Hatco Ultra-Glo® UGAL-18D Dual Ceramic Infrared Strip Heater
18" wide • standard wattage • integrated lightsGet powerful, even holding in the smallest footprint Hatco offers. The 18-inch Ultra-Glo® UGAL-18D blankets food with dual-ceramic infrared heat while shatter-resistant bulbs showcase every dish. Perfect for pass-through windows, buffets, and open-kitchen displays.
Key benefits
- Dual ceramic elements deliver a pre-focused pyramidal heat pattern that targets plate edges where heat-loss is highest.
- Increased mounting height improves operational clearance without sacrificing temperature.
- Built-in incandescent lights (one per 12") enhance food presentation and use coated, shatter-resistant bulbs for safety.
- Rigid, continuous extruded aluminum housing eliminates sagging and is available in optional designer or gloss finishes.
- Adjustable angle brackets and a 3" (76 mm) spacer are included for effortless, precise installation.
- Choose either an attached control box or a remote control enclosure—both feature a toggle switch, infinite heat control, and indicator light.
- 3' (914 mm) conduit whip supplied for quick hard-wire connection.
- Ceramic heating elements are warranted against burnout for one full year.
Perfect for
- QSR pass-through shelves
- Back- or front-of-house holding stations
- Carving stations & self-serve buffets
- Open-kitchen merchandising lines
Technical specifications
| Model | UGAL-18D |
|---|---|
| Overall width | 18" (457 mm) |
| Heat source | Dual ceramic tiles, standard wattage |
| Wattage & amps (lights included) |
1060 W / 8.8 A @ 120 V 1040 W / 5.2 A @ 120/208 V 1060 W / 4.7 A @ 120/240 V 1142 W / 5.2 A @ 220 V 1060 W / 4.4 A @ 240 V |
| Electrical | Single phase, hard-wired (3' conduit whip supplied) |
| Controls | Attached box or remote enclosure with toggle switch, infinite heat control & indicator light |
| Mounting hardware | 3" (76 mm) spacer & adjustable angle brackets (included) |
| Certifications | NSF • UL • cULus |
| Shipping weight | 17 lb (8 kg) |
| Country of origin | Made in USA |
Need a different length, high-watt model, or custom color? Contact us for a quote on any Ultra-Glo® size from 18" – 72".
