Hatco UGAHL-48 Ultra-Glo® Heat Lamps
Description
Ultra-Glo® 48" Ceramic Infrared Strip Heater – High Watt with Lights
Model UGAHL-48 | Hatco Corporation | Made in USAHold plated meals, pans or trays at perfect serving temperature while putting them in the spotlight. Hatco’s Ultra-Glo® high-watt infrared heater pairs a powerful ceramic heat strip with brilliant display lighting in a slim, 48-inch aluminum housing that installs easily over pass-throughs, buffets, or expo lines.
Why you’ll love it
- High-watt ceramic emitter blankets the entire 48" holding zone with intense, even infrared heat.
- Integrated display lights keep food looking fresh and appetizing (standard 60 W bulbs, halogen or LED optional).
- Adjustable angle brackets included—focus heat exactly where you need it and accommodate varied countertop layouts.
- Choice of controls: attached box for quick install or remote enclosure to keep electronics away from the heat zone.
- Rugged, one-piece extruded aluminum housing prevents sagging on long runs.
- Certified NSF & cULus for sanitation and safety; built and supported in Milwaukee, WI.
Perfect for
- Restaurant pass-through windows & expo counters
- Buffet lines and carving stations
- C-stores, delis, cafés and quick-serve hold areas
- Banquet plating & catering operations
Technical Specs
| Heat Source | Single ceramic infrared strip, high watt |
|---|---|
| Overall Dimensions | 48 W × 9 D × 2.5 H in (1219 × 227 × 64 mm) |
| Wattage / Amps * | Up to 2,265 W | 9.1 – 11.7 A (varies by voltage) |
| Voltage | 120/208 V, 120/240 V, 220 V or 240 V, single phase |
| Lighting | Standard 60 W incandescent (1 lamp per 12") – halogen or Chef-LED available |
| Controls | Toggle switch & indicator (attached or remote box), 3' (914 mm) conduit whip leads |
| Construction | Continuous extruded aluminum housing with adjustable angle brackets |
| Certifications | NSF, cULus |
| Country of Origin | United States of America |
*Values shown for high-watt model; refer to spec sheet for full electrical data.
Remote control enclosures must be installed outside the heat zone.
Factory Options (order-time)
- Designer Color or Gloss finishes to match your décor
- Extra lamps or halogen lamp upgrade
- Chef-LED adjustable bulbs (3 000 K / 4 000 K)
- Non-adjustable tubular stands (14" – 22") for portable setups
- Extended power leads up to 20' (6 m)
Backed by Hatco’s renowned 24/7 parts & service assistance (U.S. & Canada).
