Hatco UGAH-48D6 Ultra-Glo® Heat Lamps
Description
Ultra-Glo® 48" Dual Ceramic Infrared Foodwarmer
Model UGAH-48D • High-Watt • Made by Hatco in the USAKeep entrées sizzling hot and presentation-perfect from the moment they leave the kitchen with Hatco’s Ultra-Glo® 48" dual ceramic strip heater. Engineered for high-volume holding areas, this high-watt model blankets a full four-foot pan rail with intense, even infrared heat—so every plate stays appetizingly fresh until service.
Why You’ll Love It
- High-watt dual ceramic elements deliver maximum heat intensity across the entire 48" zone.
- 6" (152 mm) factory-supplied spacer raises the heater for a generous 22" (559 mm) working clearance—ideal for plating and carving stations.
- Continuous extruded aluminum housing prevents sagging and is light enough for simple overhead installation.
- Comes ready to mount with adjustable angle brackets and a 3' (914 mm) conduit whip.
- Choose the control style that suits your line: attached box for quick hook-up or an RMB remote enclosure to keep switches out of the heat zone.
- NSF & UL listed for safe commercial operation; all ceramic elements are warranted against burnout for one full year.
- Proudly Made in the USA and supported by 24/7 Hatco service.
Technical Specifications
| Overall width | 48" (1219 mm) |
|---|---|
| Heat source | Dual ceramic infrared – high watt |
| Wattage | 3,900 W @ 240 V - or - 4,050 W @ 208 V |
| Electrical |
208 V — 2 × 2025 W, 2 × 9.7 A 240 V — 2 × 1950 W, 2 × 8.1 A (Two circuits; each requires a separate breaker) |
| Mounting height | 22" (559 mm) with included 6" spacer |
| Housing finish | Anodized aluminum (designer & gloss colors available at order) |
| Controls | Toggle switch & indicator light — attached or remote; infinite heat control available |
| Shipping weight | Approx. 40 lb (19 kg) — add 2-8 lb for a remote control enclosure |
| Certifications | NSF, UL, CE |
| Warranty | 1-year parts & labor • 1-year ceramic element burnout coverage |
Need a different width (18–72"), color or tubular stand? Ask us about the full Ultra-Glo® range and factory options.
