Hatco UGA-54D6 Ultra-Glo® Heat Lamps
Description
Hatco Ultra-Glo® 54" Dual Ceramic Infrared Foodwarmer
Model UGA-54D | Standard Wattage | Dual Ceramic TilesTurn every pass-thru, expo window or buffet line into a high-performance holding station. Hatco’s Ultra-Glo® UGA-54D blankets a full 54 inch (1372 mm) span with focused infrared heat, locking in flavor, texture and plate appeal without over-cooking or drying out your menu items.
Why You’ll Love It
- Dual ceramic emitters deliver intense, even heat across the entire holding zone.
- Integrated 6″ spacer raises the heater to 18–22″ working clearance for easy plating and safer operation.
- Rugged, continuous extruded aluminum housing resists sagging and corrosion.
- Pre-focused pyramidal heat pattern drives warmth to the edges—where food loses heat fastest.
- Ships with adjustable-angle mounting brackets and a 3′ pre-wired conduit whip for fast installation.
- Choose attached controls (on-board toggle & indicator) or a remote control enclosure for flush-mount convenience.
- NSF listed, UL EPH Classified and proudly Made in the USA.
Perfect For
- Kitchen expo & pass-through shelves
- Buffet & carving stations
- Catering pick-up lines & banqueting
- Carry-out and staging areas
Key Specifications
| Model | UGA-54D (dual ceramic, standard wattage) |
|---|---|
| Overall width | 54 in / 1372 mm |
| Heat source | Two rows of high-intensity ceramic tiles |
| Total wattage | 3000 W @ 240 V (2 × 1500 W circuits) 2940 W @ 208 V (2 × 1470 W circuits) 3780 W @ 220 V (2 × 1890 W circuits) |
| Amperage | 2 × 6.3 A @ 240 V | 2 × 7.1 A @ 208 V |
| Mounting height (with 6″ spacer) | 18–22 in / 457–559 mm above counter |
| Housing finish | Clear anodized aluminum (14 designer & gloss colors available) |
| Shipping weight | Approx. 42 lb / 19 kg |
| Certifications | NSF, UL EPH Classified |
| Warranty | 1-year parts & labor, plus 1-year no-burnout warranty on ceramic elements |
Popular Options (factory-installed)
- Designer color or gloss finishes to complement any décor
- Non-adjustable tubular stands (18″–26″ heights)
- Extended power leads up to 20′
- Color-matched remote control enclosure with infinite switch & indicator light
Need a different size, voltage or lighting option? Ultra-Glo® models are available in widths from 18″ to 72″ and with integrated shatter-resistant bulbs. Contact us for custom quotes.
