Hatco  |  Ultra-Glo®  |  SKU: UGA-42D3

Hatco UGA-42D3 Ultra-Glo® Heat Lamps

$1,644.60
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hatco Ultra-Glo® 42" Dual Ceramic Infrared Foodwarmer

Model UGA-42D | Standard Wattage | Remote or Attached Controls

Keep entrées, sides and plated orders at peak serving temperature without sacrificing quality. The Ultra-Glo® UGA-42D surrounds a full 42 inch pass-thru or buffet section with focused, even infrared heat—so food stays hot and appetizing from the first plate to the last.

Why Operators Choose Ultra-Glo®
  • Dual ceramic infrared tiles deliver intense yet gentle heat for unmatched holding power.
  • 3 in. (76 mm) spacer raises the heater for better working clearance and safer plating.
  • Pre-focused pyramidal heat pattern blankets the entire holding area, including the vulnerable edges.
  • Rigid, one-piece extruded aluminum housing eliminates sagging across the 42 in. span.
  • Factory-supplied adjustable angle brackets mount quickly to shelves, soffits or ceiling rails.
  • Select an attached control box or a remote toggle/infinite control enclosure to suit your layout.
  • NSF & UL listed, 100 % Made in the USA, and backed by Hatco’s renowned service network.
Perfect For
  • Quick-serve & fast-casual pass-thru windows
  • Expo stations in open kitchens
  • Buffet lines, carving stations & cafeterias
  • Banquet holding shelves & catering set-ups
Key Specifications
Overall width 42 in. / 1067 mm
Heat source Dual ceramic infrared tiles (standard wattage)
Total wattage 2,240 – 2,520 W (voltage-dependent)
Voltage options 208 V, 220 V or 240 V, 1-phase, two 3-wire circuits
Amperage 10.0 – 11.4 A total
Housing profile 2.5 in. H × 3.8 in. D (64 mm × 97 mm)
Mounting clearance Min. 1 in. (25 mm) above shelf & 3 in. (76 mm) from back wall
Finish Anodized aluminum standard; designer colors & gloss finishes available at order
Certifications NSF, UL, UL-EPH
Included With Your Purchase
  • Ultra-Glo® UGA-42D strip heater
  • 3 in. (76 mm) spacer kit
  • Adjustable mounting brackets & 3 ft. (914 mm) conduit whip
  • Factory-installed attached control box or separate remote control enclosure
  • 1-year replacement warranty on all ceramic heating elements

Looking for custom colors, longer power leads or LED display lights? Contact us for a tailored Ultra-Glo® configuration.

Installation Notice: Remote control enclosures must be mounted outside the heat zone to prevent damage. Follow the Hatco installation & operating manual for complete safety guidelines.

Features & Specs

Manufacturer

Hatco

Brand_name

Ultra-Glo®

Certifications

NSF, UL, Made in USA

Height

3.8in

Width

42.0in

Depth

19.0in

Shipping Weight

32.0lbs

Size

double

Finish

aluminum

Type

unlighted

Length

37 - 42"

Type of element

ceramic heating

Specifications

Ultra-Glo® Infrared Foodwarmer, 42" W, standard wattage, double ceramic tile with aluminum housing, 3" spacer, with remote or attached control box, adjustable angle brackets, NSF, UL, Made in USA
