Hatco HWBLI-5MA Steam Tables & Food Wells
Hatco HWBLI-5MA Steam Tables & Food Wells is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Hatco HWBLI-5MA Steam Tables & Food Wells
Description
Hatco Drop-In 5-Well Modular Heated Well with Auto-Fill & Manifold Drain
Model HWBI-5MA | 5 Full-Size Pans | 120 V Low-WattEngineered for busy service lines that need dependable hot holding and effortless clean-up, the Hatco HWBI-5MA combines five individually controlled wells, automatic water management and a one-touch drain manifold—all in a single, top-mounted drop-in unit.
Key Benefits
- Five insulated full-size (12 × 20 in) wells deliver uniform temperatures for entrées, sides and sauces.
- Remote thermostat and separate lighted rocker switch for each well provide precise, independent control.
- Built-in auto-fill keeps water at the ideal level automatically—no more constant monitoring.
- 1" NPT manifold drain empties all wells at once for fast, splash-free clean-up (field-selectable left or right exit).
- Low-wattage 3,750 W design runs on a standard 120 V/60/1 circuit while maintaining rapid heat recovery.
- Heavy-duty stainless-steel top and aluminized-steel housing resist corrosion and daily wear.
- EZ-Locking hardware allows simple, above-counter installation—drop it in, twist and tighten.
- Service-friendly construction lets you replace elements or thermostats without removing the unit.
- 6 ft (1.8 m) pre-wired conduit gives flexibility when positioning the control box.
- CE, cULus and UL EPH Classified—meets strict electrical and sanitation standards.
At-a-Glance Specs
| Pan Capacity | 5 full-size steam table pans (wet or dry*) |
|---|---|
| Overall Dimensions | 71.5" W × 23.63" D × 9.56" H (1816 × 600 × 243 mm) |
| Construction | Stainless-steel top, aluminized-steel body; fully insulated |
| Controls | 5 remote thermostats with individual power switches |
| Heating Element | Metal-sheathed, field-replaceable |
| Electrical | 120 V / 60 Hz / 1-phase • 3,750 W • 31.3 A (hard-wire) |
| Water Management | Automatic fill with water level sensor |
| Drain | Integrated 1" NPT copper manifold with single shut-off valve |
| Certifications | CE • cULus • UL EPH Classified |
| Origin | Made in USA |
*For dry holding, be sure all water is drained from wells before operation.
Ideal For
- Supermarket and in-store deli hot bars
- High-volume buffets and cafeterias
- Stadium, arena and concession stands
- Back-of-house holding stations
What’s in the Box
- Hatco HWBI-5MA drop-in heated well assembly
- Factory-installed auto-fill package
- Integrated 1" manifold drain with valve
- EZ-Lock installation hardware
- 6-ft (1.8 m) electrical conduit to remote control box
- Installation & operation manual
Installation Notice: Unit must be hard-wired and plumbed by a qualified professional in accordance with local codes. Three-phase wiring is not available on 120 V models.
