Hatco HWBLI-4M Steam Tables & Food Wells
Description
Hatco HWBI-4M Low-Watt Drop-In Modular Heated Well
4-Pan | 120 V | 3000 W | Manifold Drain | Made in USAGive every entrée the perfect holding temperature with Hatco’s insulated, top-mounted 4-well module. Engineered for quick installation and effortless clean-up, the HWBI-4M brings Hatco’s legendary durability to buffets, cafeterias, and make-line stations that run on a single 120-volt circuit.
Why You’ll Love It
- 4 full-size (12 × 20 in) wells built into one seamless drop-in unit.
- Remote thermostat & separate lighted rocker switch give each well precise, independent control.
- Low-watt 3000 W system holds food safely while cutting energy costs.
- Manifold drain with 1 in NPT outlet empties all wells through a single connection—no more pan-by-pan draining.
- 50 % larger drain openings with flat screens resist clogs and keep pans level.
- EZ-Locking hardware lets you mount the unit from the top in minutes—no underside access required.
- Rugged stainless-steel well and aluminized steel housing endure daily commercial abuse.
- Quick-change design lets you swap a heating element or thermostat without removing the well.
- Complies with CE, cULus, and UL EPH sanitation standards.
- Designed & manufactured in Wisconsin, USA.
At-a-Glance Specs
| Pan Capacity | 4 full-size steam-table pans (12 × 20 in each) |
|---|---|
| Overall Dimensions (W × D × H) | 57.5 × 23.63 × 9.56 in (1461 × 600 × 243 mm) |
| Cut-Out Width / Depth | Min 56.125 × 22.25 in • Max 56.375 × 22.50 in |
| Electrical | 120 V / 60 Hz / 1-ph, 3000 W, 25 A (hard-wired with 6 ft conduit) |
| Drain Connection | 1 in NPT manifold – side or bottom exit (field selectable) |
| Construction | Stainless-steel well, aluminized steel exterior, fully insulated |
| Agency Listings | cULus, UL EPH Classified, CE |
| Country of Origin | United States of America |
Ideal Applications
- Full-service & self-serve buffets
- School & hospital cafeterias
- Supermarket hot bars
- QSR make-lines and expo counters
- Catering & banquet service islands
Popular Add-Ons (sold separately)
- Swanstone® simulated-stone well covers – convert any well into a heated shelf overnight.
- Stainless steel food pans & wire trivets (¼, ½, and full sizes).
- Round-pan adapters for soup or sauce service.
- External copper drain manifold with individual shut-off valves.
Need a different voltage, auto-fill, or split control boxes? 1- to 6-well configurations are available—chat with us for a custom quote.
