Hatco HWBLI-2MA Steam Tables & Food Wells

Hatco Drop-In 2-Pan Modular Heated Well – Auto-Fill & Manifold Drain

Hold entrées, sides or sauces at the perfect serving temperature without wasting energy or counter space. Hatco’s insulated, low-watt drop-in heated well gives you the performance of a full steam table in one sleek, easy-to-install module that handles two full-size food pans – complete with automatic water fill and a single 1 inch manifold drain.

Built for busy service lines

• Individually controlled twin wells keep different menu items at separate, precise temperatures.
• Auto-fill sensor maintains a consistent water level for worry-free wet operation.
• Copper 1" NPT manifold drain empties both wells through one connection – field-selectable left or right outlet.
• Remote control box mounts up to 6 ft (1.8 m) away and features a lighted On/Off rocker plus thermostatic dial.
• Low-watt design draws only 1,500 W (≈ 12.5 A at 120 V), reducing utility costs while meeting NSF safe holding requirements.
• EZ-Lock top-mount hardware drops in from above the counter for fast, silicone-free installation.
• Fully insulated 18-gauge stainless steel well with aluminized steel exterior minimises heat loss and keeps surrounding surfaces cool.
• 50 % larger flat-screen drain strainer resists clogs and keeps pans level.
• Elements and thermostats can be swapped out in minutes, slashing downtime.
• CE, cULus & UL EPH Classified – safe, sanitary and globally compliant.

Perfect for

• Self-serve buffets & salad bars
• Fast-casual or QSR make-lines
• Convenience-store hot food programs
• Catering drop stations & hotel breakfast bars

Technical specifications

Popular add-ons (sold separately)

• Simulated stone Swanstone® well covers – convert the unit to a heated shelf in seconds.
• Stainless or plated wire trivets for casserole dishes and displayware.
• Adapters to hold two 4-qt or 7-qt round inset pans per well.
• External drain shut-off valves and remote ¾" drain handle kits.
