Hatco HWBLI-2DA Steam Tables & Food Wells
Description
Drop-In Modular/Ganged Heated Well – 2-Pan, Auto-Fill & Drain
Hatco model HWBI-2DA • 120 V Low-WattGive your buffet, line or self-serve station a professional, built-in appearance while holding two full-size steam-table pans at precise, food-safe temperatures. Hatco’s HWBI-2DA combines rugged construction with labor-saving auto-fill and oversized drains, making daily operation and cleanup effortless.
Why choose the HWBI-2DA?
- Two individually controlled, insulated wells accept full-size 12 × 20 in (GN 1/1) pans or fractional equivalents.
- Low-watt 1 500 W system (≈ 750 W per well) delivers gentle, even heat on a standard 120 V/60/1 circuit—perfect for limited-power sites.
- Built-in auto-fill maintains proper water level automatically, reducing labor and preventing element burnout.
- Remote thermostatic control box with separate lighted power switch for each well offers quick, accurate adjustments front-of-house or under-counter.
- 50 % larger ¾ in NPT drains with flat screens speed emptying and keep pans level.
- EZ-Lock® mounting hardware lets one person drop the unit in and secure it from above the counter—no awkward underside bolting.
- Stainless-steel well and flange with aluminized-steel housing withstand daily commercial use; solid-brazed joints eliminate leaks.
- 6 ft (1 829 mm) flexible conduit supplied for convenient control-box placement.
- Made in the USA and fully certified (cULus, UL EPH, CE) for peace of mind.
Product Specifications
| Pan capacity | (2) full-size 12 × 20 in (305 × 508 mm) wells |
|---|---|
| Overall dimensions | 29.5 in W × 23.63 in D × 9.56 in H (749 × 600 × 243 mm) |
| Mounting style | Top-mounted, drop-in with EZ-Lock® tabs |
| Controls | Remote thermostats (1 per well) with lighted rocker On/Off switches |
| Temperature range | Up to 200 °F (93 °C) holding (adjustable) |
| Water management | Automatic water-level control | Individual ¾ in NPT drains |
| Electrical | 120 V | 60 Hz | 1-Phase | 1 500 W | 12.5 A Optional NEMA 5-20P cord kit available |
| Construction | Stainless-steel wells & flange, aluminized-steel exterior, high-density insulation |
| Certifications | cULus Listed, UL EPH Classified, CE Marked |
| Country of origin | Made in USA |
Designed to Make Your Job Easier
- Quick-change design lets you replace a heating element or thermostat without removing the well from the counter.
- Large, easy-grip drain handle speeds turnover between menu periods.
- Optional well covers transform the unit into a heated display shelf for off-peak times (dry mode only).
Electrical installation must conform to all applicable codes and should be performed by a qualified electrician.
