Hatco HWBLI-1DA Steam Tables & Food Wells
Description
Hatco HWBI-1DA Low-Watt Drop-In Heated Well
Single Pan • Auto-Fill & Drain • 120 V / 750 WDeliver consistent, food-safe holding temperatures from a compact cut-out. The Hatco HWBI-1DA is a fully insulated, top-mounted heated well that keeps one full-size steam-table pan hot, fresh and ready to serve—without hot spots, guesswork or constant refills.
Why you’ll love it
- Remote mechanical thermostat with a lighted rocker switch puts precision control at your fingertips.
- Factory-installed auto-fill maintains the water level automatically for worry-free wet operation.
- Oversized ¾" NPT drain with flat filter screen speeds clean-up and keeps pans level.
- Low-watt 750 W element is perfect for 120 V locations where power is at a premium.
- Stainless steel well and aluminized exterior stand up to daily commercial use.
- EZ-Lock mounting hardware allows fast, one-person drop-in installation—no tools required.
- Operates wet or dry to accommodate entrées, sides, soups and sauces.
- 6 ft (1829 mm) flexible conduit lets you position the control box exactly where you need it.
- Independently certified—UL, cUL, CE and UL EPH Classified—for peace of mind worldwide.
At-a-glance specs
| Model | HWBI-1DA (Low Watt) |
|---|---|
| Pan capacity | 1 × Full-size steam-table pan (12" × 20" / 305 × 508 mm) |
| Dimensions (W × D × H) | 15.5" × 23.63" × 9.56" (394 × 600 × 243 mm) |
| Electrical | 120 V • 60 Hz • 1-phase • 750 W • 6.3 A (NEMA 5-15P cord plug option) |
| Controls | Remote thermostat & lighted On/Off rocker switch |
| Water management | Auto-fill solenoid plus ¾" NPT drain |
| Construction | Stainless steel well, aluminized exterior, solid-brazed drain fittings |
| Installation | Top-mount drop-in with EZ-Lock tabs (optional factory-installed gasket available) |
| Agency approvals | UL • cUL • CE • UL EPH Classified (NSF/ANSI 4) |
| Origin | Made in USA |
Ideal applications
- Hot bars and buffets
- Supermarket delis & grab-and-go kiosks
- Convenience stores and snack bars
- Back-of-house holding on the cook line
Need more pans? Hatco Modular/Ganged Heated Wells are available in 1- to 6-pan configurations. Contact us for details.
What’s in the box
- HWBI-1DA heated well
- Remote control box with 6 ft conduit
- EZ-Lock installation hardware
- Auto-fill solenoid & ¾" drain assembly (pre-installed)
- Installation & operating manual
Cut-out guidance: Always verify countertop cut-out dimensions and clearances in the installation manual before making permanent modifications.
