Hatco  |  SKU: HWBI43-6

Hatco HWBI43-6 Steam Tables & Food Wells

$5,504.35
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Color chart Owner's manual Parts list Catalog brochure
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hatco HWBI43-6 Drop-In Modular/Ganged Heated Well

(6) 4/3-size wells • Individual remote controls • Made in USA

Create a seamless, high-capacity steam table in one easy cut-out. The Hatco HWBI43-6 combines six insulated 4/3-size wells into a single, top-mounted module that keeps entrées, sides and sauces at safe serving temperatures for extended periods—without sacrificing food quality.

Key benefits at a glance
  • Six independent wells – each 4/3-size cavity holds
    • 4 third-size pans
    • 2 half-size pans + 1 third-size pan
    • 1 full-size pan + 1 third-size pan
  • Precise holding – dedicated thermostat dial and lighted ON/OFF rocker switch for every well.
  • Fast, clean installation – EZ-Locking™ hardware secures the unit tight to the countertop—no silicone bead required when factory gasket option is chosen.
  • Lasting build quality – stainless-steel well with aluminized exterior, solid-brazed drain fittings and extra-deep design for longer holding times.
  • Service-friendly – elements and thermostats can be swapped out quickly from the top side.
  • Operator-focused – 50 % larger drain (when specified) speeds cleanup and keeps pans level.
  • Certified & compliant – cULus, CE and UL EPH Classified (NSF/ANSI 4) for worldwide peace of mind.
Technical specifications
Model HWBI43-6 (insulated, top-mount)
Well count / size 6 × 4/3-size rectangular wells
Overall dimensions (W × D × H) 85.5″ × 30.375″ × 9.62″ (2172 × 772 × 244 mm)
Electrical 208 V or 240 V; single- or 3-phase
7,215 W max.
6′ (1829 mm) flexible conduit included
Controls Remote mechanical thermostats with separate lighted rocker switches (1 set per well)
Construction Stainless-steel well liner, aluminized exterior, factory insulation
Shipping weight Approx. 214 lb (97 kg)
Certifications cULus, CE, UL EPH Classified; ANSI/NSF 4 compliant
Country of origin Made in the USA
Ideal applications
  • Buffet lines & cafeterias
  • Universities & corporate dining
  • Supermarket hot bars
  • Catering and banquet service
Important: This unit must be installed in a water-resistant countertop cut-out and wired by a qualified technician to the voltage and phase listed on the product data plate. Always maintain water level to the “HOLD” line for optimal food safety.

Need drains, auto-fill, split control boxes or other options? Contact us before ordering—Hatco custom-builds every HWBI43-6 to match your workflow.

Features & Specs

Manufacturer

Hatco

Certifications

CE, cULus, UL EPH Classified, Made in USA

Height

9.62in

Width

85.5in

Depth

30.38in

Shipping Weight

214.0lbs

Insulated or Non-Insulated

insulated

Drain

without drain

Controls

thermostatic controls

Style

individual pans

Pan Capacity

(6) 4/3 size (12" x 27")

Construction

stainless steel top, corrosion resistant steel exterior

Wet or Dry operation

wet or dry

Specifications

Drop-In Modular/Ganged Heated Well, (6) 4/3 size pan capacity, insulated, top mounted, remote thermostat dial with separate on/off rocker switch, EZ locking hardware, stainless steel & aluminized construction, CE, cULus, UL EPH Classified, Made in USA
