Hatco HWBI43-5DA Steam Tables & Food Wells
Description
Hatco HWBI43-5DA Drop-In Modular/Ganged Heated Well
5-Well • Auto-Fill & Drain • 4/3-Size • Made in USABuild a high-throughput steam table in one clean, drop-in package. The HWBI43-5DA combines five individually controlled, insulated wells with factory-installed drain and auto-fill systems, giving you rock-solid temperature holding, effortless refills and rapid clean-up—everything you expect from Hatco’s flagship built-in line.
Key Features
- Five 4/3-size wells grouped in one top-mount frame for a seamless counter cut-out.
- Auto-fill system with low-water sensor keeps elements safely covered and eliminates manual refilling.
- ¾″ NPT drains per well plus 50 % larger flat-screen strainers speed end-of-day clean-up.
- Remote thermostat dial with separate lighted On/Off rocker switch for each well.
- Stainless-steel top & liner with aluminized steel housing and solid-brazed joints for long-term durability.
- Factory insulation delivers quicker heat-up and longer holding times—no hot edges on your counter.
- EZ-Lock mounting hardware clamps the unit tight in seconds; no silicone bead required when ordered with factory gasket.
- 6 ft (1.8 m) flexible conduit included for convenient control-box placement.
- Built to the toughest standards: CE, cULus, UL EPH Classified (NSF 4).
- Proudly engineered and manufactured in Milwaukee, Wisconsin, USA.
Better Holding, Happier Guests
Deeper than a standard full-size well, Hatco’s 4/3-size cavity wraps pans in a gentle water bath that locks in moisture and flavour. Expect creamy mac & cheese, juicy proteins and silky sauces—hour after hour.
Pan Configurations (per well)
- 4 × 1/3-size pans
- 2 × 1/2-size pans + 1 × 1/3-size pan
- 1 × full-size pan + 1 × 1/3-size pan
Specifications
| Model | HWBI43-5DA |
|---|---|
| Well Count / Size | 5 insulated 4/3-size wells (top mount) |
| Overall Dimensions | 71.5″ W × 30.375″ D × 9.62″ H (1816 × 772 × 244 mm) |
| Counter Cut-Out | 70.19–70.37″ W × 29.188–29.438″ D (1783–1788 mm × 742–748 mm) |
| Electrical | 208–240 V, 6,015 W, single-phase standard (three-phase available at order) |
| Auto-Fill | Factory installed; low-water sensor & solenoid valve |
| Drain | Individual ¾″ NPT with flat-screen strainers |
| Conduit Length | 6 ft (1.8 m) flexible conduit supplied |
| Approx. Ship Weight | ≈ 197 lb / 89 kg |
| Certifications | CE, cULus, UL EPH Classified |
| Origin | Made in USA |
Optional Accessories (sold separately)
- Stainless food pans: 1/3, 1/2 & full-size (2.5″, 4″ & 6″ deep)
- 11 qt (10 L) round inset pans with hinged or notched lids
- Stainless wire trivets & support bars
- Copper drain manifold with individual shut-off valves
- Gate or ball valves (¾″ or 1″ NPT) & remote drain handles
Need additional wells or digital controls? The Hatco HWBI43 series is available in 1- to 6-well configurations with multiple control and manifold options. Reach out for a tailored quote.
