Hatco HWBI-S2DA Steam Tables & Food Wells
Description
Hatco HWBI-S2DA Drop-In Modular Slim Heated Well — 2 Full-Size Pans
Auto-Fill • Built-In Drain • Wet/Dry Operation • Remote Thermostat ControlBring precise, dependable hot-holding to your buffet or serving line without sacrificing valuable counter space. The Hatco HWBI-S2DA Slim Heated Well groups two full-size wells lengthwise in a single, fully-insulated module that is simple to install, easy to service and effortless to operate.
Key Advantages
- Accepts two full-size 12 × 20 in pans (or fractional pans with adapters).
- Wet or dry heat – fill for gentle steam holding or run dry for convected heat versatility.
- Auto-fill maintains water level automatically to protect elements and save labor.
- Oversized ¾ in NPT drain with flat strainer empties wells fast and simplifies cleanup.
- Independent remote thermostat for each well plus a separate, lighted power switch.
- Full fiberglass insulation keeps heat on the food and surrounding surfaces cooler for guests.
- Durable stainless-steel wells with aluminized steel housing and brazed drain fittings.
- Includes EZ-Lock hardware and a 6 ft (1.8 m) conduit for quick, secure drop-in mounting.
- Complies with the toughest standards – CE, cULus & UL EPH Classified.
- Made in the USA and supported 24/7 by Hatco’s parts & service team.
Ideal For
- Buffets, cafeterias & hotels
- Convenience stores & supermarkets
- Catering lines & banqueting operations
- Commissary and ghost-kitchen buildup stations
Technical Specifications
| Model | HWBI-S2DA (standard watt) |
|---|---|
| Pan Capacity | 2 × full-size 12 × 20 in steam-table pans |
| Overall Dimensions (W × D × H) | 45.5 × 15.625 × 9.56 in (1156 × 397 × 243 mm) |
| Countertop Cut-Out | 44.125–44.375 × 14.25–14.50 in (1121–1127 × 362–368 mm) |
| Electrical | 240 V, 1-phase, 2.4 kW, 10.1 A (208 V & 220-230 V options available) |
| Controls | Remote mechanical thermostats (1 per well) with separate illuminated On/Off switch |
| Water Connections | Auto-fill inlet & ¾ in NPT drain (individual or manifolded) |
| Construction | Stainless steel wells, aluminized steel housing, brazed drain fittings |
| Agency Approvals | CE • cULus • UL EPH Classified |
| Ship Weight | Approx. 84 lb (38 kg) |
| Country of Origin | Made in USA |
Optional Accessories (sold separately)
- Swanstone® simulated-stone heated well covers for one-pan merchandising.
- Adapter bars & stainless trivets for third-, half- or round-pan layouts.
- Full-, half- & third-size stainless food pans in 2½ in, 4 in & 6 in depths.
- Ball or gate valves for remote drain actuation.
Installation must comply with all local electrical and plumbing codes. Professional installation is strongly recommended.
