Hatco HWBI-3M Steam Tables & Food Wells
Description
Hatco HWBI-3M Drop-In Modular Heated Well (3-Pan, Manifold Drain)
Top-mounted | Individually controlled | Made in USAKeep entrées, sides and toppings hot, fresh and food-safe in one sleek, easy-to-install unit. The Hatco HWBI-3M combines three full-size wells, precision remote controls and a single copper manifold drain to deliver reliable holding with minimal clean-up or counter cut-outs.
Why you’ll love it
- Three full-size (12 × 20 in) wells grouped in a single drop-in module.
- Separate remote thermostat and lighted rocker switch for each well.
- Factory-installed 1 in NPT copper manifold drain clears all wells through one outlet.
- 50 % larger drain opening with flat screen keeps pans level and speeds clean-up.
- Fully insulated stainless-steel & aluminized housing retains heat, saves energy.
- EZ-Lock hardware secures the unit from above the counter in seconds—no studs, no sealant.
- Wet or dry operation for maximum menu flexibility.
- Front-serviceable design—swap elements or thermostats without removing the well.
- 6 ft (1829 mm) flexible conduit included for convenient control-box placement.
Certifications that matter
- cULus Listed
- UL EPH Classified (ANSI/NSF 4)
- CE Marked
- Manufactured in Wisconsin, USA
Specs at a glance
| Pan capacity | 3 × full-size (12 × 20 in / 305 × 508 mm) |
|---|---|
| Overall dimensions | 43.5 in W × 23.63 in D × 9.56 in H (1105 × 600 × 243 mm) |
| Counter cut-out (EZ-Lock) |
42.375–43.31 in W × 22.25–22.50 in D (1076–1100 mm W × 565–571 mm D) |
| Drain | 1 in NPT copper manifold, side or bottom exit (field selectable) |
| Controls | Remote thermostats (3) with independent lighted on/off switches |
| Power (standard-watt) | 3 615 W @ 208 V or 4 250 W @ 240 V, single or three-phase |
| Construction | Stainless steel top; aluminized steel housing; full fiberglass insulation |
| Approx. ship weight | ≈ 103 lb (47 kg) |
Looking for auto-fill, split controls or a matching 27 in deep bezel? Ask us about other Hatco HWBI configurations built to order.
