Hatco HWBI-3D Steam Tables & Food Wells
Description
Hatco HWBI-3D Drop-In Modular Heated Well
3-Pan | Standard Watt | With Drains | Made in USAServe entrées, sides and sauces at perfect, food-safe temperatures—without sacrificing counter space or presentation. Hatco’s HWBI-3D Drop-In Modular/Ganged Heated Well is a fully insulated, top-mounted unit that groups three full-size wells in one seamless module and gives each well its own precision thermostat. Built for demanding commercial kitchens, the HWBI-3D combines rugged stainless & aluminized steel construction with smart features that make installation, operation and cleanup faster than ever.
Why You’ll Love It
- Three individual 12" × 20" (305 × 508 mm) wells—ideal for hotel pans, gastronorm pans or round adapters.
- Integrated ¾" NPT drains with flat screens are 50 % larger for quicker cleanup and level pan support.
- Remote control box with separate lighted rocker switch & temperature dial for each well.
- 6' (1829 mm) flexible conduit provides convenient control-box placement.
- EZ Locking hardware speeds up drop-in installation—no extra tools or guesswork.
- Fully insulated design delivers faster heat-up and longer holding time while saving energy.
- Field-serviceable elements and thermostats minimize downtime.
- Certified safe & sanitary: CE, cULus, and UL EPH Classified.
- Proudly engineered and manufactured in Milwaukee, Wisconsin, USA.
At-a-Glance Specifications
| Model | HWBI-3D (Standard Watt) |
|---|---|
| Pan Capacity | 3 full-size pans (12" × 20") |
| Overall Dimensions | 43.5" W × 23.63" D × 9.56" H (1105 × 600 × 243 mm) |
| Construction | Stainless steel well & lip, aluminized steel housing |
| Controls | Remote thermostats with separate illuminated power switches (one per well) |
| Electrical | 208–240 V, single or three-phase, 3615–3750 W (Other voltages & phase options available) |
| Drain Connection | Individual ¾" NPT drains (side exit standard) |
| Agency Listings | CE • cULus • UL EPH Classified |
| Approx. Ship Weight | 103 lb (47 kg) |
| Country of Origin | United States of America |
Popular Factory Options
- Bottom-exit or manifold drain configurations
- Auto-fill water system
- Split control boxes (remote left/right) for custom layouts
- 27" (686 mm) deep bezel to match Hatco CWB refrigerated wells
- Gasketed lip for silicone-free installation
Compatible Accessories
- Swanstone® simulated-stone well covers (1- or 2-pan) convert the unit to a heated shelf.
- Stainless or plated trivets, round soup pan adapters, hinged & notched lids.
- External copper drain manifolds with individual shut-off valves.
Electrical ratings, cut-out dimensions and installation requirements vary by voltage, phase and options selected. Always consult the current Hatco specification sheet and installation manual before ordering or cutting countertops. Pans, lids and accessories sold separately.
