Hatco HWBI-2M Steam Tables & Food Wells
Description
Drop-In Modular/Ganged Heated Well – 2-Pan, Manifold Drain
Hatco Model HWBI-2 • Standard-Watt • Made in USAGive every entrée the perfect serve-ready temperature without giving up counter space. The Hatco HWBI-2 insulated drop-in well combines two full-size steam-table wells into one sleek, top-mounted module, complete with a 1 in. NPT manifold drain, remote thermostatic controls and Hatco’s legendary build quality.
Why You’ll Love It
- Holds two full-size (12 in × 20 in / 305 × 508 mm) pans – each well independently heated and controlled.
- Remote control box with lighted On/Off rocker switch and easy-read temperature dial for each well.
- Precision-engineered, insulated wells deliver faster heat-up and longer holding times while reducing energy loss.
- Oversized 1 in. manifold drain with flat stainless screen makes clean-up quick and keeps pans level.
- Stainless-steel top flange & aluminized-steel body – resists corrosion and stands up to daily commercial use.
- EZ-Locking hardware lets you secure the well from the top in seconds – no crawling under the counter.
- 6 ft (1829 mm) flexible conduit included for convenient remote mounting of the control box.
- Field-selectable left or right drain outlet for hassle-free installation.
- Meets the toughest standards – cULus, CE & UL EPH Classified.
At-a-Glance Specs
| Pan Capacity | 2 × full-size steam-table pans (12 in × 20 in) |
|---|---|
| Overall Dimensions (W × D × H) | 29.5 in × 23.63 in × 9.56 in (749 × 600 × 243 mm) |
| Mounting | Top-mounted, drop-in; includes EZ-Lock clamps |
| Drain | 1 in. NPT manifold drain (side-exit, field selectable) |
| Electrical | 208–240 V, 1-ph, 2415 W 11.6 A @ 208 V • 10.1 A @ 240 V |
| Controls | Remote thermostats with individual lighted power switches |
| Construction | Stainless-steel top bezel; aluminized-steel well & housing; brazed drain fittings |
| Certifications | cULus • CE • UL EPH Classified (NSF/ANSI 4) |
| Approx. Ship Weight | 73 lb (33 kg) |
| Country of Origin | USA |
Popular Add-Ons *
- Swanstone® simulated-stone well covers – convert the well to a heated shelf for merchandising after hours.
- Full- & half-size stainless-steel pans, 2.5 in to 6 in deep.
- Ball or gate valves for easy plumbing shut-off.
- Round-pan adapters, trivets and support bars.
*Accessories sold separately.
Need a different size or auto-fill option? Check out the full Hatco HWBI family or talk to us for a custom configuration.
