Hatco HCWBIX-5DA Steam Tables & Food Wells
Hatco HCWBIX-5DA Steam Tables & Food Wells is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Hatco HCWBIX-5DA Steam Tables & Food Wells
Description
Hatco Remote Drop-In Hot/Cold Well – 5 Pan
Model HCWBIR-5DA • Switch from chilled to piping-hot service in one wellFrom breakfast buffets to dinner service, this versatile Hot/Cold Well lets you hold five full-size pans at perfect serving temperature—whether that’s crisp, refreshing salads or sizzling entrées. Hatco’s proven FR2 Hydro-Heater, remote R-513A refrigeration and intuitive electronic controls give you reliable performance in a footprint that disappears into your counter.
Key benefits
- Dual-mode operation with a simple COLD – OFF – HOT rocker switch and separate digital read-outs.
- FR2 Hydro-Heater “free-flow” Bain-Marie system delivers gentle, even heat up to 192 °F (89 °C) and features automatic water-fill, drain and low-water safety shut-off.
- Cold mode includes auto-defrost and an angled interior that blankets food with cold air to maintain 10 – 50 °F (-12 – 10 °C).
- 5/8 HP remote condensing unit (shipped loose) can be mounted up to 50 ft away to reduce noise and heat at the counter.
- Remote-mount electronic control panel (mount within 5 ft) arrives with a 60 in power-supply whip for fast installation.
- Pan support bars for both hot and cold service are included—accommodates (5) full-size 12 × 20 in pans or fractional equivalents.
- Heavy-duty stainless & aluminized steel construction; cULus listed component and proudly Made in the USA.
Specifications
| Capacity | (5) full-size 12 × 20 in pans, up to 6 in deep |
|---|---|
| Overall dimensions | 71 in W × 27 in D × 26.54 in H (1803 × 686 × 674 mm) |
| Counter cut-out | 69.125 – 70 in W × 25.19 – 26 in D (1756 – 1778 × 640 – 660 mm) |
| Well depth | 12 in (305 mm) |
| Temperature range | Cold 10 – 50 °F (-12 – 10 °C) • Hot 65 – 192 °F (18 – 89 °C) |
| Heating system | 6000 W FR2 Hydro-Heater with auto-fill & drain |
| Refrigeration | Remote R-513A condensing unit, 5/8 HP compressor (shipped loose) |
| Electrical | 120/208 V or 120/240 V 1 Φ 28.8 A (208 V) • 1 Φ 14.5 A (240 V) • 3 Φ 16.7 A (208 V) |
| Controls | Remote electronic panel with digital temperature displays & programmable set points |
| Certifications | cULus, NSF component |
| Origin | Made in USA |
Allow a minimum of 60 minutes for the well to transition between hot and cold modes.
