Hatco  |  SKU: HCWBIR-2DA

Hatco HCWBIR-2DA Steam Tables & Food Wells

$8,085.83
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Parts list Owner's manual Catalog brochure
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hatco HCWBIR-2DA Remote Drop-In Hot/Cold Well

2-Pan | Switchable Refrigerated or Heated Service

Serve sizzling entrées at breakfast and chilled salads at lunch—all from the same well. The Hatco HCWBIR-2DA combines an energy-efficient FR2 hydro-heater with a high-performance remote refrigeration system, giving you precise, push-button control over both hot and cold holding in a single drop-in footprint.

Key Features

  • Hot OR Cold at the flip of a switch—digital readouts for each mode.
  • Pan capacity: (2) full-size 12 × 20 in. pans; accepts fractional pans with optional dividers.
  • Remote electronic control panel mounts to any vertical surface within 20 ft (6.1 m) of the well.
  • Cold mode: auto-defrost system and angled interior walls for even air blanket.
  • Hot mode: 3 kW FR2 hydro-heater with automatic water fill, drain & low-water protection.
  • Remote condensing unit (1/5 HP) ships loose—install up to 50 ft (15.24 m) away for quieter front-of-house operation.
  • Eco-friendly R-513A refrigerant meets the latest environmental standards.
  • Includes hot-mode pan supports & cold-mode pan support bars—no extra accessories to buy.
  • cULus & NSF component listed; proudly Made in the USA.

Perfect For

  • Breakfast buffets & brunch lines
  • Self-serve salad or deli bars
  • Hotel & resort banquets
  • Supermarket grab-and-go islands

Technical Specifications

Model HCWBIR-2DA
Pan Capacity (2) full-size 12 × 20 in. (GN 1/1) pans
Temperature Range Cold 10–50 °F (-12–10 °C)  |  Hot 65–192 °F (18–89 °C)
Heating System FR2 Hydro-Heater, 3000 W, automatic water fill & drain
Refrigeration 1/5 HP remote condensing unit, R-513A refrigerant
Controls Remote-mount panel with digital thermostats & COLD-OFF-HOT rocker switch
Voltage Options 120/208 V 1-ph 14.5 A | 120/208 V 3-ph 8.4 A | 120/240 V 3-ph 7.3 A
Overall Dimensions 32 W × 27 D × 26.54 H in.
Counter Cut-Out 30.125–31 W × 25.19–26 D in.
Power Connection 60 in. pre-wired flexible conduit (field hard-wired)
Certifications cULus, NSF Component
Country of Origin USA

Allow approximately 60 minutes for full transition between hot and cold modes.

Installation Required: Condensing unit, TXV valve, hydro-heater, and control panel ship loose for field mounting. Professional refrigeration & electrical connection is recommended.

Features & Specs

Manufacturer

Hatco

Certifications

cULus, Made in USA

Height

26.5in

Width

32.0in

Depth

27.0in

Shipping Weight

214.0lbs

Pan Qty

2-pan

Cooling Style

mechanically cooled

Controls

single controls

Type

hot/cold

Finish

stainless steel top & well, aluminized steel exterior

Specifications

Drop-In Hot/Cold Well, accommodates (2) full-size pans, condensing unit, FR2 hydro-heater, TXV valve, remote mountable panel, 60" power supply whip, electronic temperature control, auto defrost, automatic water fill, condensing unit, comes with pan support bars, 3000 watts, 1/5 HP, cULus, Made in USA
