Hatco GRAIHL-66D6 Glo-Ray® Heat Lamps
Description
Hatco Glo-Ray® 66" Dual Infra-Black Strip Heater with Lights
Model GRAIHL-66D • High-Watt 3420 W • NSF, CE, cULusKeep every plate “just-made” hot and picture-perfect at the pass-thru. Hatco’s Glo-Ray® dual Infra-Black heater surrounds food with a continuous blanket of even heat while five bright display lamps showcase your menu items in the best possible light. Built, tested and certified in the USA, it is the proven solution for wide, high-volume holding areas.
Key advantages
- High-watt dual Infra-Black emitters (3420 W) eliminate hot spots across the full 66" span.
- 6" (152 mm) spacer delivers an extra-deep 18" heat zone for bulky platters and sheet pans.
- Five 60 W shatter-resistant display bulbs included; optional halogen or LED upgrades available.
- Extruded aluminum double housing resists sagging and stays cool thanks to heavy insulation.
- Metal-sheathed elements carry a 2-year no-burn-out guarantee.
- Requires remote control box (toggle, infinite or thermostatic) for precise temperature management.
- Designer powder-coat colors, gloss finishes and antimicrobial coatings let you match any décor.
- Certified NSF, CE and cULus for safe use worldwide.
- Made in Milwaukee, Wisconsin, USA.
At-a-glance specs
| Model | GRAIHL-66D |
|---|---|
| Overall width | 66" / 1676 mm |
| Depth | 18" / 457 mm (with 6" spacer) |
| Height | 2.6" / 66 mm |
| Wattage | Up to 3420 W (240 V) |
| Voltage options | 120/208 V, 120/240 V, 208 V, 220 V or 240 V, single-phase |
| Max amperage | 17.5 A (120/208 V) |
| Heating elements | Dual metal-sheathed Infra-Black® |
| Display lights | 5 × 60 W incandescent (standard) |
| Construction | Extruded aluminum, anodized finish |
| Ship weight | ≈ 45 lb / 21 kg |
| Certifications | NSF • CE • cULus |
| Origin | Made in USA |
Mount 8"–14" (203–356 mm) above a metallic target surface for optimum performance. Maintain at least 10" (254 mm) clearance in front of any overshelf.
Popular factory options
- Halogen display bulbs (3000 K warm or 4000 K cool)
- Protective element wire guards
- Non-adjustable tubular stands (4"–14" clearances)
- Chain suspension kit or adjustable angle brackets for under-shelf mounting
- Designer color or gloss finish housings with matching remote boxes
Upgrade your hot holding line today and experience the uniform heat, rugged build and unmistakable reliability of Hatco’s Glo-Ray® GRAIHL-66D.
