Hatco  |  Glo-Ray®  |  SKU: GRAIHL-54D3

Hatco GRAIHL-54D3 Glo-Ray® Heat Lamps

$1,284.48
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Color chart Owner's manual Catalog brochure
Related Searches
Heat Lamps Serving & Display Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hatco Glo-Ray® 54" High-Watt Dual Infra-Black Strip Heater with Lights

Model GRAIHL-54D  |  2740 W

Give every dish the temperature—and spotlight—it deserves. Hatco’s GRAIHL-54D blankets a 54-inch service zone with even Infra-Black heat while four bright display bulbs keep food looking irresistible and sales moving fast.

Top benefits

  • Dual high-watt heating panels deliver uniform heat across the entire holding area—no hot or cold spots.
  • Infra-Black metal-sheathed elements are warrantied for 2 years against burnout or breakage.
  • Four shatter-resistant 60 W display lights showcase food and improve visibility for staff.
  • Built-in 3" (76 mm) spacer positions the heater for optimal performance 8–14" above product.
  • Extruded aluminum housing won’t sag, resists corrosion and stays cool to the touch.
  • Heavy-duty insulation keeps heat focused on the food, not your kitchen.
  • NSF, CE & cULus listed and proudly Made in the USA.

Perfect for

  • Pass-thru windows and expo lines
  • Buffets and cafeteria counters
  • Quick-service holding stations
  • Carving or plating areas

Specifications

Model GRAIHL-54D
Overall width 54" (1372 mm)
Housing depth / height 15" D × 2.6" H (381 × 66 mm)
Element spacing 3" (76 mm) dual housing
Heat output 2740 W
Typical voltages 120/208 V, 120/240 V or 240 V, 1-phase
Amperage (240 V) ≈ 11.4 A
Display lights 4 × 60 W clear bulbs (standard)
Shipping weight 39 lb (18 kg)
Certifications NSF, CE, cULus
Country of origin USA
Installation note: This high-watt model requires wiring to a remote control enclosure (sold separately). Mount the enclosure outside of the heat zone to prevent damage.

Need another size, finish or control option? Glo-Ray® Strip Heaters are available from 18"–72" with a full palette of Designer Color and Gloss finishes—contact us for a custom quote.

Features & Specs

Manufacturer

Hatco

Brand_name

Glo-Ray®

Certifications

NSF, cULus, Made in USA

Height

2.5in

Width

54.0in

Depth

15.0in

Shipping Weight

39.0lbs

Finish

aluminum

Size

double

Type

lighted

Length

49 - 54"

Type of element

black panel heating system

Specifications

Glo-Ray® Infrablack Strip Heater, 54" W, high wattage with lights, metal sheathed heating element, double heater housing 3" spacing, aluminum construction, 2740 watts, NSF, CE, cULus, Made in USA
