Hatco  |  Glo-Ray®  |  SKU: GRAH-144D6

Hatco GRAH-144D6 Glo-Ray® Heat Lamps

$2,227.01
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options

Documents

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Hatco Glo-Ray® Dual Infrared Strip Heater – 144"

Model GRAH-144D | 6" Spacer | High Watt | Tandem Elements

When your serving line stretches a full 12 feet, only a heater this powerful will do. Hatco’s Glo-Ray® GRAH-144D bathes every inch of food in a pre-focused blanket of infrared warmth—keeping entrées hot and appetizing without drying them out or creating cold spots.

Why you’ll love it

  • Dual tubular metal heater rods deliver even, high-intensity heat across the entire 144" span.
  • 6" (152 mm) center spacer creates a deeper heat field for bulk pans and taller products.
  • 6900 watts of infrared power (208 V) with heavy-duty insulation to minimize energy loss.
  • Tandem end-to-end elements (108–144" models) allow independent section control for off-peak savings.
  • Rigid extruded aluminum housing won’t sag; reinforced wire guards protect staff without blocking heat.
  • Reflector won’t blacken, so the heat pattern —and presentation—stay consistent over time.
  • NSF & cULus listed and Made in the USA for unsurpassed build quality and code compliance.

Perfect for

  • Buffet lines & catering stations up to 12 ft
  • Wide pass-through windows between kitchen & service areas
  • Institutional dining, stadium concessions and banquet operations

Technical specs

Model GRAH-144D (High Watt)
Overall length 144" / 3658 mm
Depth × Height 18" × 2.5" (457 × 64 mm) – 6" spacer version
Heating elements Dual tubular metal rods with tandem (independent) end control
Wattage 6900 W @ 208 V | 6800 W @ 240 V
Amperage 33.2 A @ 208 V | 28.4 A @ 240 V
Clearance above combustibles 10" (254 mm) minimum
Certifications NSF, cULus
Country of origin USA
Warranty 2-year element warranty & 24/7 parts/service support

Factory options

Customize with Designer Color housings, sneeze guards, tubular stands, remote toggle or infinite switches, and RMB remote control enclosures. Contact us for a quote tailored to your line-up.

Installation reminder: This high-wattage unit must be hard-wired by a qualified electrician. Remote control boxes must be mounted outside the heat zone to prevent damage.

Need a shorter length or different wattage? Ask about Glo-Ray® dual heaters from 18" to 144" in both standard and high-watt models.

Features & Specs

Manufacturer

Hatco

Brand_name

Glo-Ray®

Certifications

NSF, cULus, Made in USA

Height

2.5in

Width

144.0in

Depth

18.0in

Shipping Weight

80.0lbs

Length

121 - 144"

Type of element

metal heating rod

Finish

aluminum

Size

double

Type

unlighted

Specifications

Glo-Ray® Infrared Strip Heater, 144" W, high wattage, tubular metal heater rod, double heater rod housing 6" spacing, aluminum construction, 6900 watts, contains tandem elements, NSF, cULus, Made in USA
