Hatco Glo-Ray® Dual Infrared Strip Heater – 132"
Model GRAH-132D • High-Watt • 6,240 WStretching a full 11 feet, the Hatco Glo-Ray® GRAH-132D blankets extra-long buffet runs, pass-through windows and plating areas with steady, pre-focused infrared warmth. Dual tubular metal-sheathed elements sit side-by-side inside a rugged aluminum housing, creating a deeper 3" heat zone that keeps every inch of food hot, appetizing and ready to serve.
Why You’ll Love It
- Even heat from end to end – tandem high-watt elements eliminate “cold spots” across the entire 132" span.
- Deep 3" spacing between the dual strips creates a broader holding area ideal for high-volume serving lines.
- High output – 6,240 watts pumps out intense infrared heat that holds food at safe temperatures without drying.
- Rugged, sag-free construction – extruded aluminum housing with reinforced wire guards built for busy kitchens.
- Clean, consistent performance – bright polished reflector will not blacken and is fully insulated to reduce heat loss.
- Certified & backed by Hatco – NSF & cULus listed, Made in the USA, with a 2-year element warranty and 24/7 parts & service support.
Ideal Applications
- Extra-long cafeterias & buffet bars
- High-volume banquet plating lines
- Pass-through windows & expo counters
- Catering commissaries & prep kitchens
Technical Specs
Overall width | 132" / 3,353 mm |
---|---|
Depth (with 3" spacer) | 15" / 381 mm |
Height | 2.5" / 64 mm |
Heating elements | Dual tubular metal-sheathed, tandem (end-to-end) |
Total wattage | 6,240 W (high-watt) |
Voltage & amps |
208 V – 30.0 A 220-230 V – 28.4-28.7 A 240 V – 26.0 A |
Electrical connection | Hard-wired; includes 36" (914 mm) flexible metal conduit with 42" (1,067 mm) leads |
Construction | Extruded aluminum housing, polished reflector, heavy-duty insulation |
Certifications | NSF • cULus • Made in USA |
Shipping weight | ≈ 73 lb / 34 kg |
Warranty | 2 years on metal-sheathed elements; 1 year parts & labor |
Recommended mounting clearance to combustible surfaces: 10" (254 mm) minimum. Unit ships without switch controls; remote toggle or infinite control boxes are available separately.
