Hatco FR-9-208-3-QS Quick Ship Steam Tables & Food Wells
Description
Hatco FR-9 Food Rethermalizer / Bain-Marie Heater – 9 kW, 208 V / 3 Ph
Quick-Ship model – order by 12 pm CT for same-day shipment*Keep soups, sauces and pre-cooked entrées safely hot and ready for service with Hatco’s most powerful Food Rethermalizer. The FR-9 delivers a full 9 kW of even, circulating heat to your water bath, bringing foods up to temperature fast and then holding them between 140 °F – 190 °F (60 °C – 88 °C) for hours of worry-free serving.
Top Benefits
- High-output 9 kW element quickly rethermalizes refrigerated or chilled foods to 165 °F in 2 hours or less.
- Energy Cut-Off (ECO) safety automatically shuts the unit down if water temperature rises abnormally high.
- Precise temperature dial lets you set and maintain your ideal holding range (140 °F – 190 °F).
- Dual drain system – separate sump and heating-compartment drains simplify cleaning and sanitizing.
- Included 2" plated-brass bulkhead fittings make under-counter installation fast and leak-free.
- Durable stainless-steel front, powder-coated silver-gray hammertone body with antimicrobial finish, and black base.
- 5-year stainless-steel tank warranty plus 24/7 parts & service support (US & Canada).
- Certified NSF, UL, UL EPH Classified, CSA, CE – Made in the USA.
Ideal For
- Cafeterias, buffets & commissaries
- Supermarkets & delis
- Restaurants & catering operations
- Concessions and convenience stores
Technical Specifications
| Model | FR-9 (Quick-Ship) |
|---|---|
| Power Rating | 9 kW |
| Electrical | 208 V / 60 Hz / 3 Phase (≈ 32.5 A) |
| Temperature Range | 140 °F – 190 °F (60 °C – 88 °C) |
| Overall Dimensions | Approx. 16.9"W × 8.5"D × 12.3"H (430 × 216 × 311 mm) |
| Shipping Weight | ≈ 30 lb (14 kg) |
| Construction | Stainless-steel tank, stainless front, powder-coated body, black base |
| Plumbing Connections | (2) × 2" NPT plated-brass bulkhead fittings (supplied) |
| Warranty | 5 years on stainless tank; 1 year parts & labor |
Installation Notes
- Designed to mount under the vessel with ≤ 3 ft of heater on either side of the tank centerline.
- Perforated water baffle (installer supplied) is required for proper circulation.
- Minimum recommended power density for food rethermalizing: 2,000 W/ft² of vessel top.
*Quick-Ship availability is inventory-dependent. Standard pricing and discounts apply. Orders placed after 12 pm CT ship the next business day.
