Hatco DHWBI-1 Steam Tables & Food Wells
Description
Hatco DHWBI-1 Drop-In Modular Dry Heated Well
1 Full-Size Pan • Remote Thermostat • 120 VGive guests perfectly held entrées and sides—without the hassle of water baths. The Hatco DHWBI-1 is a single-well, dry, drop-in warmer that uses uniform convected heat to maintain safe, appetizing temperatures in any 12" × 20" pan. Built for performance, serviceability, and easy installation, it’s a smart upgrade for any serving line where plumbing isn’t practical.
Key benefits
- Dry convected heat surrounds the pan evenly—no water, no steam, no lime scale.
- Remote electronic thermostat with dedicated On/Off switch holds precise temps from prep to closing.
- Fully insulated stainless & aluminized housing maximizes heat retention while keeping exterior surfaces cooler.
- Integrated ¾" NPT brass drain speeds clean-up of accidental spills and protects the fan assembly.
- Top-access service design lets technicians replace elements or fans without removing the well from the counter.
- 6 ft (1829 mm) flexible conduit gives installers freedom to mount the control box where staff can reach it easily.
- cULus & UL EPH Classified for electrical and sanitation compliance.
- Proudly engineered and manufactured in Milwaukee, Wisconsin, USA.
Perfect for
- Quick-service & fast-casual lines
- Supermarket hot cases
- Convenience stores
- Buffet or catering drop-ins
- Any location without easy water access
Technical specifications
| Capacity | One full-size pan (12" × 20") up to 6" deep |
|---|---|
| Overall size (W × D × H) | 15.5" × 23.625" × 12.64" (394 × 600 × 321 mm) |
| Countertop cut-out | 14.125"–14.375" W × 22.25"–22.5" D (359–365 mm × 566–571 mm) |
| Voltage | 120 V, 1-phase |
| Wattage / Amps | 960 W | 8 A |
| Control box opening | 6.313" W × 4.698" H (160 × 119 mm) |
| Standard plug | NEMA 5-15P (factory-installed cord & plug option) |
| Drain | ¾" NPT brass spill drain |
| Construction | Stainless steel top & bezel, aluminized steel body, full fiberglass insulation |
| Ship weight | 40 lb (18 kg) |
| Certifications | cULus, UL EPH Classified, ANSI/NSF 4 |
| Warranty & support | 24/7 parts-and-service assistance (US & Canada) |
Popular accessories (sold separately)
- Full-size stainless pans: 2.5", 4", or 6" deep
- Wire trivets for spillage pans
- Round-pan adapters (two 4-qt or two 7-qt)
- 12" and 20" support bars
- Factory-installed gasket—no silicone caulk required
Looking for multiple wells? Hatco offers 2- to 6-pan DHWBI units— contact us for layout and quoting assistance.
