Hatco | SKU:
CWBX-S1
Hatco CWBX-S1 Steam Tables & Food Wells
$3,583.20
Unit price
/
Unavailable
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Hatco CWBX-S1 Steam Tables & Food Wells is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Description
Hatco CWBX-S1 Slim Remote Drop-In Refrigerated Well
1 full-size pan • top-mount • remote-ready (no condensing unit)Keep salads, desserts and cold entrées at food-safe temperatures without sacrificing precious counter space. The Hatco CWBX-S1 is a NSF 7-listed cold-wall well that holds a single full-size 12" × 20" pan lengthwise, providing a sleek, low-profile solution for buffet lines, cafés and convenience stores that rely on a remote refrigeration system.
Why you’ll love it
- Remote refrigeration design ships without a condensing unit so you can connect to an existing rack or locate the compressor out of sight for a quieter, cooler serving area.
- Electronic temperature control (control panel shipped loose, 9 ft probe lead) offers precise set-points and automatic defrost to maintain product quality.
- NSF 7 cold-wall construction blankets food with gentle, even chill to prevent drying and meet holding standards.
- Space-saving slim profile fits where traditional 2-pan wells can’t—perfect for narrow counter runs or made-to-order stations.
- Angled interior walls increase coil surface area, speeding pull-down times and improving visibility of displayed items.
- 1" NPT brass drain with removable strainer simplifies end-of-day cleanup.
- Durable aluminized-steel housing with an attractive stainless-steel bezel resists corrosion and matches surrounding equipment.
- Eco-friendly insulation on sides and bottom locks cold in, lowering energy demand and operating costs.
- cULus Listed & Made in the USA for safety, quality and faster parts availability.
Technical Specifications
| Model | CWBX-S1 |
|---|---|
| Pan capacity | 1 full-size (12" × 20") pan or combination of fractional pans (bars required, sold separately) |
| Exterior dimensions | 27.06" W × 18.94" D × 17.11" H (687 × 481 × 435 mm) |
| Counter cut-out | 25.22–26.06" W × 17.06–17.94" D (641–662 mm × 433–456 mm) |
| Evaporator load | 330 BTU/hr |
| Electrical | 120 V / 60 Hz or 220/230/240 V / 50-60 Hz (select at time of order) Electronic control panel powered separately from condensing unit |
| Drain connection | 1" NPT |
| Shipping weight | Approx. 94 lb (43 kg) |
| Certifications | NSF 7, cULus |
Popular Accessories (sold separately)
- Pan support bars (12" / 305 mm) for fractional pan layouts
- Stainless-steel hotel pans – 2.5", 4" or 6" deep
- Perforated false bottoms & stainless wire trivets for ice-on-bottom presentations
- Gasket kit for tool-free, silicone-free counter installation
- 5° slant kit to enhance product visibility
- Remote condensing unit & refrigeration line set (field-supplied)
Important: This model is shipped without a condensing unit.
It must be connected to a compatible remote refrigeration system before operation.
Looking for other pan capacities? Hatco offers 2-, 3- and 4-pan Slim wells—ask us for details.
Features & Specs
Features & Specs
Manufacturer
Hatco
Certifications
Made in USA
Height
17.13in
Width
27.06in
Depth
19.0in
Shipping Weight
94.0lbs
Insulation
insulated
Finish
aluminum & stainless steel
Style
remote refrigeration (no compressor)
Width (side - side)
19 - 24 inches
Pan Qty
1-pan
Layout
straight
Pan Size
full-size (12" x 20")
Specifications
Slim Drop-In Refrigerated Well, (1) pan size, top mount, electronic temperature control, auto defrost, remote refrigeration, control panel & TXV valve (shipped loose), insulated with 1" drain, aluminized steel housing, stainless steel bezel, with control panel, WITHOUT condensing unit, cULus, Made in USA
