Hatco CWBX-1 Steam Tables & Food Wells
Description
Hatco CWBX-1 Remote Refrigerated Drop-In Well – 1 Pan
Top-mount cold-wall well with electronic temperature control | Condensing unit not includedKeep salads, toppings and chilled desserts safely below 41 °F without the noise or heat of a built-in compressor. The Hatco CWBX-1 installs flush in your counter and connects to a remote refrigeration system, giving you a cleaner look, more storage space and a quieter front-of-house.
Why you’ll love it
- Single-well design holds one full-size 12" × 20" pan (or fractional equivalents).
- NSF 7-approved cold-wall construction with R-513A refrigerant keeps food cold without drying it out.
- Angled interior walls “blanket” product with cold air for even chilling and better visibility.
- Ships ready for remote refrigeration – TXV valve (loose) and factory-installed solenoid valve included.
- Advanced electronic controller with auto-defrost; 9 ft (2.7 m) probe lead lets you mount the digital control panel where it’s most convenient.
- 1" NPT brass drain and full foam insulation streamline cleaning and cut energy loss.
- Durable aluminized-steel housing with stainless-steel bezel matches other Hatco drop-ins for a seamless line-up.
- cULus listed, NSF certified and proudly made in the USA.
Specifications
| Model | CWBX-1 |
|---|---|
| Pan capacity | (1) Full-size 12" × 20" pan (6" max depth) or fractional pans |
| Overall dimensions | 19" W × 27" D × 10.5" H (483 × 686 × 267 mm) |
| Required cut-out | 17 1/8"–18" W × 25 3/16"–26" D (435–457 mm × 640–660 mm) |
| Evaporator load | 330 BTU/h |
| Electrical | 120 V / 60 Hz or 220-240 V / 50-60 Hz (control circuit only) |
| Drain | 1" NPT brass, bottom-center |
| Housing | Aluminized steel, fully insulated |
| Bezel | Stainless steel, top-mount |
| Shipping weight | 94 lb (43 kg) |
| Certifications | NSF 7, cULus |
| Country of origin | Made in USA |
Optional accessories (sold separately)
- Pan support bars (12" or 20")
- Perforated false bottoms
- Stainless-steel food pans
- 5° slant kit for improved merchandising
- Remote condensing unit & line-set packages
Need help matching a condensing unit or choosing accessories? Reach out via live chat or our contact page and we’ll be happy to assist.
