Hatco CWBR-1 Steam Tables & Food Wells

Hatco CWBR-1 Remote Refrigerated Drop-In Well

Keep salads, desserts and other pre-chilled menu items at food-safe temperatures without sacrificing presentation or counter space. The CWBR-1 is Hatco’s smallest Remote Refrigerated Drop-In Well, built to hold a single full-size 12" × 20" pan while delivering the same cold-wall performance trusted by leading buffets, cafeterias and convenience stores.

Key benefits

• NSF-7 approved cold-wall design blankets food with cold air — no fans to dry product out.
• Unique angled interior walls provide better product visibility and easier access for staff and guests.
• Electronic temperature control with programmable auto-defrost for set-and-forget operation.
• Remote 1/5 HP condenser (R-513A refrigerant) reduces heat and noise at the serving line; may be mounted up to 50 ft (15.24 m) away.
• Service-ready package includes sight glass, service valves, TXV valve and filter-drier — all shipped loose for field installation.
• 1" NPT brass drain and fully insulated aluminized-steel housing speed daily clean-up.
• Stainless-steel bezel matches other Hatco wells for a seamless, professional look.
• cULus listed, NSF-7 certified and proudly Made in the USA.

Ideal for

• Salad bars & cold ingredient stations
• Cafeteria and buffet service lines
• Grab-and-go countertops in c-stores & delis
• Catering and banquet operations that require quiet, remote refrigeration

Technical specifications

What’s included

• CWBR-1 drop-in refrigerated cold well
• Remote condensing unit with sight glass & service valves
• Electronic control panel (9 ft probe leads)
• TXV valve & filter-drier (loose)
• Installation & operation manual

Pans, pan support bars, false bottoms and other accessories are sold separately.
